A company is using a combination of API Gateway and Lambda for the web services of the online web portal that is being accessed by hundreds of thousands of clients each day. They will be announcing a new revolutionary product and it is expected that the web portal will receive a massive number of visitors all around the globe.
How can you protect the backend systems and applications from traffic spikes?

• A.Manually upgrade the EC2 instances being used by API Gateway
• B.Deploy Multi-AZ in API Gateway with Read Replica
• C.Use throttling limits in API Gateway
• D.API Gateway will automatically scale and handle massive traffic spikes so you do not have to do anything.

Correct Answer: C

Amazon API Gateway provides throttling at multiple levels including global and by a service call.
Throttling limits can be set for standard rates and bursts. For example, API owners can set a rate limit of 1000 requests per second for a specific method in their REST APIs, and also configure Amazon API Gateway to handle a burst of 2,000 requests per second for a few seconds.
Amazon API Gateway tracks the number of requests per second. Any requests over the limit will receive a 429 HTTP response. The client SDKs generated by Amazon API Gateway retry calls automatically when met with this response.


Hence, the correct answer is: Use throttling limits in API Gateway.
The option that says: API Gateway will automatically scale and handle massive traffic spikes so you do not have to do anything is incorrect. Although it can scale using AWS Edge locations, you still need to configure the throttling to further manage the bursts of your APIs.
Manually upgrading the EC2 instances being used by API Gateway is incorrect because API Gateway is a fully managed service and hence, you do not have access to its underlying resources.
Deploying Multi-AZ in API Gateway with Read Replica is incorrect because RDS has Multi-AZ and Read Replica capabilities, and not API Gateway.
Explanation:
Reference:
https://aws.amazon.com/api-gateway/faqs/#Throttling_and_Caching
Check out this Amazon API Gateway Cheat Sheet:
https://tutorialsdojo.com/amazon-api-gateway/

Comment: *

Name: *

Email: *

Verification: *

A tech company is currently using Auto Scaling for their web application. A new AMI now needs to be used for launching a fleet of EC2 instances.
Which of the following changes needs to be done?

• A.Create a new target group.
• B.Create a new launch configuration.
• C.Do nothing. You can start directly launching EC2 instances in the Auto Scaling group with the same launch configuration.
• D.Create a new target group and launch configuration.

Correct Answer: B

A launch configuration is a template that an Auto Scaling group uses to launch EC2 instances. When you create a launch configuration, you specify information for the instances such as the ID of the Amazon Machine Image (AMI), the instance type, a key pair, one or more security groups, and a block device mapping. If you've launched an EC2 instance before, you specified the same information in order to launch the instance.

You can specify your launch configuration with multiple Auto Scaling groups. However, you can only specify one launch configuration for an Auto Scaling group at a time, and you can't modify a launch configuration after you've created it. Therefore, if you want to change the launch configuration for an Auto Scaling group, you must create a launch configuration and then update your Auto Scaling group with the new launch configuration.
For this scenario, you have to create a new launch configuration. Remember that you can't modify a launch configuration after you've created it.
Hence, the correct answer is: Create a new launch configuration.
The option that says: Do nothing. You can start directly launching EC2 instances in the Auto Scaling group with the same launch configuration is incorrect because what you are trying to achieve is change the AMI being used by your fleet of EC2 instances. Therefore, you need to change the launch configuration to update what your instances are using.
The option that says: create a new target group and create a new target group and launch configuration are both incorrect because you only want to change the AMI being used by your instances, and not the instances themselves. Target groups are primarily used in ELBs and not in Auto Scaling. The scenario didn't mention that the architecture has a load balancer. Therefore, you should be updating your launch configuration, not the target group.
References:
http://docs.aws.amazon.com/autoscaling/latest/userguide/LaunchConfiguration.html
https://docs.aws.amazon.com/autoscaling/ec2/userguide/AutoScalingGroup.html Check out this AWS Auto Scaling Cheat Sheet: https://tutorialsdojo.com/aws-auto-scaling/

Comment: *

Name: *

Email: *

Verification: *

A DevOps Engineer is required to design a cloud architecture in AWS. The Engineer is planning to develop a highly available and fault-tolerant architecture consisting of an Elastic Load Balancer and an Auto Scaling group of EC2 instances deployed across multiple Availability Zones. This will be used by an online accounting application that requires path-based routing, host-based routing, and bi-directional streaming using Remote Procedure Call (gRPC).
Which configuration will satisfy the given requirement?

• A.Configure an Application Load Balancer in front of the auto-scaling group. Select gRPC as the protocol version.
• B.Configure a Network Load Balancer in front of the auto-scaling group. Create an AWS Global Accelerator accelerator and set the load balancer as an endpoint.
• C.Configure a Gateway Load Balancer in front of the auto-scaling group. Ensure that the IP Listener Routing uses the GENEVE protocol on port 6081 to allow gRPC response traffic.
• D.Configure a Network Load Balancer in front of the auto-scaling group. Use a UDP listener for routing.

Correct Answer: A

Application Load Balancer operates at the request level (layer 7), routing traffic to targets (EC2 instances, containers, IP addresses, and Lambda functions) based on the content of the request. Ideal for advanced load balancing of HTTP and HTTPS traffic, Application Load Balancer provides advanced request routing targeted at delivery of modern application architectures, including microservices and container-based applications. Application Load Balancer simplifies and improves the security of your application, by ensuring that the latest SSL/TLS ciphers and protocols are used at all times.

If your application is composed of several individual services, an Application Load Balancer can route a request to a service based on the content of the request such as Host field, Path URL, HTTP header, HTTP method, Query string, or Source IP address.

ALBs can also route and load balance gRPC traffic between microservices or between gRPC-enabled clients and services. This will allow customers to seamlessly introduce gRPC traffic management in their architectures without changing any of the underlying infrastructure on their clients or services.
Therefore, the correct answer is: Configure an Application Load Balancer in front of the auto-scaling group. Select gRPC as the protocol version.
The option that says: Configure a Network Load Balancer in front of the auto-scaling group. Use a UDP listener for routing is incorrect. Network Load Balancers do not support gRPC.
The option that says: Configure a Gateway Load Balancer in front of the auto-scaling group. Ensure that the IP Listener Routing uses the GENEVE protocol on port 6081 to allow gRPC response traffic is incorrect. A Gateway Load Balancer operates as a Layer 3 Gateway and a Layer 4 Load Balancing service. Do take note that the gRPC protocol is at Layer 7 of the OSI Model so this service is not appropriate for this scenario.
The option that says: Configure a Network Load Balancer in front of the auto-scaling group. Create an AWS Global Accelerator accelerator and set the load balancer as an endpoint is incorrect. AWS Global Accelerator simply optimizes application performance by routing user traffic to the congestion-free, redundant AWS global network instead of the public internet. References:
https://aws.amazon.com/elasticloadbalancing/features
https://aws.amazon.com/elasticloadbalancing/faqs/
AWS Elastic Load Balancing Overview:
https://youtu.be/UBl5dw59DO8
Check out this AWS Elastic Load Balancing (ELB) Cheat Sheet:
https://tutorialsdojo.com/aws-elastic-load-balancing-elb/
Application Load Balancer vs Network Load Balancer vs Gateway Load Balancer:
https://tutorialsdojo.com/application-load-balancer-vs-network-load-balancer-vs-classic-load-balancer/

Comment: *

Name: *

Email: *

Verification: *

A tech company currently has an on-premises infrastructure. They are currently running low on storage and want to have the ability to extend their storage using the AWS cloud.
Which AWS service can help them achieve this requirement?

• A.Amazon Elastic Block Storage
• B.Amazon EC2
• C.Amazon SQS
• D.Amazon Storage Gateway

Correct Answer: D

AWS Storage Gateway connects an on-premises software appliance with cloud-based storage to provide seamless integration with data security features between your on-premises IT environment and the AWS storage infrastructure. You can use the service to store data in the AWS Cloud for scalable and cost- effective storage that helps maintain data security.

Amazon EC2 is incorrect since this is a compute service, not a storage service.
Amazon Elastic Block Storage is incorrect since EBS is primarily used as a storage of your EC2 instances.
Amazon SQS is incorrect since this is a message queuing service, and does not extend your on- premises storage capacity.
Explanation:
Reference:
http://docs.aws.amazon.com/storagegateway/latest/userguide/WhatIsStorageGateway.html AWS Storage Gateway Overview:
https://youtu.be/pNb7xOBJjHE
Check out this AWS Storage Gateway Cheat Sheet:
https://tutorialsdojo.com/aws-storage-gateway/
Tutorials Dojo's AWS Certified Solutions Architect Associate Exam Study Guide:
https://tutorialsdojo.com/aws-certified-solutions-architect-associate-saa-c02/

Comment: *

Name: *

Email: *

Verification: *

A company has a web application that is relying entirely on slower disk-based databases, causing it to perform slowly. To improve its performance, the Solutions Architect integrated an in-memory data store to the web application using ElastiCache.
How does Amazon ElastiCache improve database performance?

• A.By caching database query results.
• B.It reduces the load on your database by routing read queries from your applications to the Read Replica.
• C.It securely delivers data to customers globally with low latency and high transfer speeds.
• D.It provides an in-memory cache that delivers up to 10x performance improvement from milliseconds to microseconds or even at millions of requests per second.

Correct Answer: A

ElastiCache improves the performance of your database through caching query results.
The primary purpose of an in-memory key-value store is to provide ultra-fast (submillisecond latency) and inexpensive access to copies of data. Most data stores have areas of data that are frequently accessed but seldom updated. Additionally, querying a database is always slower and more expensive than locating a key in a key-value pair cache. Some database queries are especially expensive to perform, for example, queries that involve joins across multiple tables or queries with intensive calculations.
By caching such query results, you pay the price of the query once and then are able to quickly retrieve the data multiple times without having to re-execute the query.


The option that says: It securely delivers data to customers globally with low latency and high transfer speeds is incorrect because this option describes what CloudFront does and not ElastiCache.
The option that says: It provides an in-memory cache that delivers up to 10x performance improvement from milliseconds to microseconds or even at millions of requests per second is incorrect because this option describes what Amazon DynamoDB Accelerator (DAX) does and not ElastiCache. Amazon DynamoDB Accelerator (DAX) is a fully managed, highly available, in-memory cache for DynamoDB.
Amazon ElastiCache cannot provide a performance improvement from milliseconds to microseconds, let alone millions of requests per second like DAX can.
The option that says: It reduces the load on your database by routing read queries from your applications to the Read Replica is incorrect because this option describes what an RDS Read Replica does and not ElastiCache. Amazon RDS Read Replicas enable you to create one or more read-only copies of your database instance within the same AWS Region or in a different AWS Region. References:
https://aws.amazon.com/elasticache/
https://docs.aws.amazon.com/AmazonElastiCache/latest/red-ug/elasticache-use-cases.html Check out this Amazon Elasticache Cheat Sheet:
https://tutorialsdojo.com/amazon-elasticache/
