A company has a three-tier application on AWS that ingests sensor data from its users' devices The traffic flows through a Network Load Balancer (NLB) then to Amazon EC2 instances for the web tier and finally to EC2 instances for the application tier The application tier makes calls to a database What should a solutions architect do to improve the security of the data in transit?

• A.Configure a TLS listener Deploy the server certrficate on the NLB
• B.Configure AWS Shield Advanced Enable AWS WAF on the NLB
• C.Change the load balancer to an Application Load Balancer (ALB) Enable AWS WAF on the ALB
• D.Encrypt the Amazon Elastic Block Store (Amazon EBS) volume on the EC2 instances by using AWS Key Management Service (AWS KMS)

Comment: *

Name: *

Email: *

Verification: *

A company is migrating a new application from an on-premises data center to a new VPC in the AWS Cloud.
The company has multiple AWS accounts and VPCs that share many subnets and applications. The company wants to have fine-grained access control for the new application. The company wants to ensure that all network resources across accounts and VPCs that are granted permission to access the new application can access the application.
Which solution will meet these requirements?

• A.Set up a VPC peering connection for each VPC that needs access to the new application VPC. Update route tables in each VPC to enable connectivity.
• B.Deploy a transit gateway in the account that hosts the new application. Share the transit gateway with each account that needs to connect to the application. Update route tables in the VPC that hosts the new application and in the transit gateway to enable connectivity.
• C.Use an AWS PrivateLink endpoint service to make the new application accessible to other VPCs.
  Control access to the application by using an endpoint policy.
• D.Use an Application Load Balancer (ALB) to expose the new application to the internet. Configure authentication and authorization processes to ensure that only specified VPCs can access the application.

Comment: *

Name: *

Email: *

Verification: *

A technical lead of the Cloud Infrastructure team was consulted by a software developer regarding the required AWS resources of the web application that he is building. The developer knows that an Instance Store only provides ephemeral storage where the data is automatically deleted when the instance is terminated. To ensure that the data of the web application persists, the app should be launched in an EC2 instance that has a durable, block-level storage volume attached. The developer knows that they need to use an EBS volume, but they are not sure what type they need to use.
In this scenario, which of the following is true about Amazon EBS volume types and their respective usage? (Select TWO.)

• A.Magnetic volumes provide the lowest cost per gigabyte of all EBS volume types and are ideal for workloads where data is accessed infrequently, and applications where the lowest storage cost is important.
• B.Spot volumes provide the lowest cost per gigabyte of all EBS volume types and are ideal for workloads where data is accessed infrequently, and applications where the lowest storage cost is important.
• C.Single root I/O virtualization (SR-IOV) volumes are suitable for a broad range of workloads, including small to medium-sized databases, development and test environments, and boot volumes.
• D.Provisioned IOPS volumes offer storage with consistent and low-latency performance, and are designed for I/O intensive applications such as large relational or NoSQL databases.
• E.General Purpose SSD (gp3) volumes with multi-attach enabled offer consistent and low-latency performance, and are designed for applications requiring multi-az resiliency.

Correct Answer: A,D

Amazon EBS provides three volume types to best meet the needs of your workloads: General Purpose (SSD), Provisioned IOPS (SSD), and Magnetic.

General Purpose (SSD) is the new, SSD-backed, general purpose EBS volume type that is recommended as the default choice for customers. General Purpose (SSD) volumes are suitable for a broad range of workloads, including small to medium sized databases, development, and test environments, and boot volumes.
Provisioned IOPS (SSD) volumes offer storage with consistent and low-latency performance and are designed for I/O intensive applications such as large relational or NoSQL databases. Magnetic volumes provide the lowest cost per gigabyte of all EBS volume types.
Magnetic volumes are ideal for workloads where data are accessed infrequently, and applications where the lowest storage cost is important. Take note that this is a Previous Generation Volume. The latest low- cost magnetic storage types are Cold HDD (sc1) and Throughput Optimized HDD (st1) volumes. Hence, the correct answers are:
- Provisioned IOPS volumes offer storage with consistent and low-latency performance, and are designed for I/O intensive applications such as large relational or NoSQL databases.
- Magnetic volumes provide the lowest cost per gigabyte of all EBS volume types and are ideal for workloads where data is accessed infrequently, and applications where the lowest storage cost is important.
The option that says: Spot volumes provide the lowest cost per gigabyte of all EBS volume types and are ideal for workloads where data is accessed infrequently, and applications where the lowest storage cost is important is incorrect because there is no EBS type called a "Spot volume" however, there is an Instance purchasing option for Spot Instances.
The option that says: General Purpose SSD (gp3) volumes with multi-attach enabled offer consistent and low-latency performance, and are designed for applications requiring multi-az resiliency is incorrect because the multi-attach feature can only be enabled on EBS Provisioned IOPS io2 or io1 volumes. In addition, multi-attach won't offer multi-az resiliency because this feature only allows an EBS volume to be attached on multiple instances within an availability zone.
The option that says: Single root I/O virtualization (SR-IOV) volumes are suitable for a broad range of workloads, including small to medium-sized databases, development and test environments, and boot volumes is incorrect because SR-IOV is related with Enhanced Networking on Linux and not in EBS.
References:
https://docs.aws.amazon.com/AWSEC2/latest/UserGuide/EBSVolumeTypes.html
https://docs.aws.amazon.com/AWSEC2/latest/UserGuide/AmazonEBS.html Check out this Amazon EBS Cheat Sheet:
https://tutorialsdojo.com/amazon-ebs/

Comment: *

Name: *

Email: *

Verification: *

A data analytics company wants to migrate its batch processing system to AWS. The company receives thousands of small data files periodically during the day through FTP. A on-premises batch job processes the data files overnight. However, the batch job takes hours to finish running.
The company wants the AWS solution to process incoming data files are possible with minimal changes to the FTP clients that send the files. The solution must delete the incoming data files the files have been processed successfully. Processing for each file needs to take 3-8 minutes.
Which solution will meet these requirements in the MOST operationally efficient way?

• A.Use AWS Transfer Family to create an FTP server to store incoming files in Amazon S3 Standard.
  Create an AWS Lambda function to process the files and to delete the files after they are proessed.yse an S3 event notification to invoke the lambda function when the fils arrive
• B.Use AWS Transfer Family to create an FTP server to store incoming files on an Amazon Elastic Block Store (Amazon EBS) volume. Configure a job queue in AWS Batch. Use an Amazon S3 event notification when each files arrives to invoke the job in AWS Batch. Delete the files after the job has processed the files.
• C.Use an Amazon EC2 instance that runs an FTP server to store incoming files as objects in Amazon S3 Glacier Flexible Retrieval. Configure a job queue in AWS Batch. Use Amazon EventBridge rules to invoke the job to process the objects nightly from S3 Glacier Flexible Retrieval. Delete the objects after the job has processed the objects.
• D.Use an Amazon EC2 instance that runs an FTP server to store incoming files on an Amazon Elastic Block Store (Amazon EBS) volume. Configure a job queue in AWS Batch. Use Amazon EventBridge rules to invoke the process the files nightly from the EBS volume. Delete the files after the job has processed the files.

Comment: *

Name: *

Email: *

Verification: *

A solutions architect is creating a new VPC design There are two public subnets for the load balancer, two private subnets for web servers and two private subnets for MySQL The web servers use only HTTPS The solutions architect has already created a security group tor the load balancer allowing port 443 from 0 0 0 0/0 Company policy requires that each resource has the teas! access required to still be able to perform its tasks Which additional configuration strategy should the solutions architect use to meet these requirements?

• A.Create a network ACL 'or the web servers and allow port 443 from the load balancer Create a network ACL for the MySQL servers and allow port 3306 from the web servers security group
• B.Create a security group for the web servers and allow port 443 from the load balancer Create a security group for the MySQL servers and allow port 3306 from the web servers security group
• C.Create a network ACL for the web servers and allow port 443 from 0.0.0.0/0 Create a network ACL (or the MySQL servers and allow port 3306 from the web servers security group
• D.Create a security group for the web servers and allow port 443 from 0.0.0.0/0 Create a security group for the MySQL servers and allow port 3306 from the web servers security group
