The company ESXi infrastructure is hosted on the Cisco UCS-B Blade Servers. The company decided to take advantage of ACI VMM integration to enable consistent enforcement of policies across virtual and physical workloads. The requirement is to prevent the packet loss between the distributed virtual switch and the ACI fabric. Which setting must be implemented on a vSwitch policy to accomplish this goal?

• A.Static Channel
• B.MAC Pinning
• C.LACP
• D.LLDP

Comment: *

Name: *

Email: *

Verification: *

Which endpoint learning operation is completed on the ingress leaf switch when traffic is received from a Layer
3 Out?

• A.The source MAC address of the traffic is learned as a local endpoint.
• B.The source MAC address of the traffic is learned as a remote endpoint.
• C.The source IP address of the traffic is learned as a remote endpoint.
• D.The source IP address of the traffic is learned as a local endpoint.

Comment: *

Name: *

Email: *

Verification: *

Which endpoint learning operation is completed on the egress leaf switch when traffic is received from an L3Out?

• A.The source MAC and IP address of the traffic is learned as a local endpoint.
• B.The source MAC address of the traffic is learned as a remote endpoint.
• C.No source MAC or IP address of the traffic is learned as a remote endpoint.
• D.The source IP address of the traffic is learned as a remote endpoint.

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

An engineer must implement the inter-tenant service graph. Which set of actions must be taken to accomplish this goal?

• A.* Define the contract in the provider tenant and export it to the consumer tenant.
  * Define the L4-L7 device and service graph template in the provider tenant and the ASA bridge domains in the consumer tenant.
• B.* Define the contract in the provider tenant and export it to the provider tenant.
  * Define the L4-L7 device, service graph template, and ASA bridge domains in the consumer tenant.
• C.* Define the contract in the provider tenant and export it to the consumer tenant.
  * Define the L4-L7 device, service graph template, and ASA bridge domains in the provider tenant.
• D.* Define the contract in the provider tenant and export it to the provider tenant.
  * Define the L4-L7 device and service graph template in the provider tenant and the ASA bridge domains in the consumer tenant.

Comment: *

Name: *

Email: *

Verification: *

What must be configured to allow SNMP traffic on the APIC controller?

• A.out-of-band management interface
• B.contract under tenant mgmt
• C.SNMP relay policy
• D.out-of-band bridge domain
