Which LISP device is responsible for publishing EID-to-RLOC mappings for a site?

• A.ETR
• B.MR
• C.ITR
• D.MS

Comment: *

Name: *

Email: *

Verification: *

What are two device roles in Cisco SD-Access fabric? (Choose two.)

• A.core switch
• B.vBond controller
• C.edge node
• D.access switch
• E.border node

Correct Answer: C,E

Explanation
There are five basic device roles in the fabric overlay:
+ Control plane node: This node contains the settings, protocols, and mapping tables to provide the endpoint-to-location (EID-to-RLOC) mapping system for the fabric overlay.
+ Fabric border node: This fabric device (for example, core layer device) connects external Layer 3 networks to the SDA fabric.
+ Fabric edge node: This fabric device (for example, access or distribution layer device) connects wired endpoints to the SDA fabric.
+ Fabric WLAN controller (WLC): This fabric device connects APs and wireless endpoints to the SDA fabric.
+ Intermediate nodes: These are intermediate routers or extended switches that do not provide any sort of SD-Access fabric role other than underlay services.

Comment: *

Name: *

Email: *

Verification: *

Which action is the vSmart controller responsible for in an SD-WAN deployment?

• A.manage, maintain, and gather configuration and status for nodes within the SD-WAN fabric
• B.onboard vEdge nodes into the SD-WAN fabric
• C.gather telemetry data from vEdge routers
• D.distribute security information for tunnel establishment between vEdge routers

Comment: *

Name: *

Email: *

Verification: *

What are two device roles in Cisco SD-Access fabric? (Choose two.)

• A.core switch
• B.vBond controller
• C.edge node
• D.access switch
• E.border node

Correct Answer: C,E

Explanation
There are five basic device roles in the fabric overlay:
+ Control plane node: This node contains the settings, protocols, and mapping tables to provide the endpoint-to-location (EID-to-RLOC) mapping system for the fabric overlay.
+ Fabric border node: This fabric device (for example, core layer device) connects external Layer 3 networks to the SDA fabric.
+ Fabric edge node: This fabric device (for example, access or distribution layer device) connects wired endpoints to the SDA fabric.
+ Fabric WLAN controller (WLC): This fabric device connects APs and wireless endpoints to the SDA fabric.
+ Intermediate nodes: These are intermediate routers or extended switches that do not provide any sort of SD-Access fabric role other than underlay services.

Comment: *

Name: *

Email: *

Verification: *

What is a characteristic of a WLC that is in master controller mode?

• A.All new APs that join the WLAN are assigned to the master controller.
• B.The master controller is responsible for load balancing all connecting clients to other controllers.
• C.All wireless LAN controllers are managed by the master controller.
• D.Configuration on the master controller is executed on all wireless LAN controllers.
