What is the sequence of steps that must be executed to implement IP Multi-tenancy in a Unity system?

• A.Create a NAS server tor each tenant
  Create file systems and shares for each tenant
  Add tenants and associate to the NAS servers
• B.Add tenants to the Unity system
  Create a NAS server for each tenant
  Create file systems and shares for each tenant
• C.Associate tenants with existing NAS servers
  Create file systems and shares for each tenant
  Configure host access for the tenant's shares
• D.Create file systems and shares for each tenant
  Configure host access for the tenant's shares
  Add tenants to the Unity System

Comment: *

Name: *

Email: *

Verification: *

A system administrator has placed the Storage Processor (SP) in Service mode for maintenance.
Using Unisphere, they notice mode field for the still both SPs as normal. What is another indicator the administrator can check to verity that the SP is in Service mode?

• A.Unsafe to remove LED is lit
• B.DPE Chassis Fault LED is solid amber
• C.SP Fault LED blinks alternating amber and blue
• D.SP Fault LED is solid blue

Comment: *

Name: *

Email: *

Verification: *

A storage administrator wants to add as asynchronous replication session to a pair of Unity systems with an existing synchronous replication session that is operating correctly. Which configuration steps are needed?

• A.Create Replication interfaces on both systems.
  Modify the Replication Connection Mode.
  Run a Replication Connection Verify and Update operation.
• B.Create Replication Interfaces on the source system.
  Modify the Mode for Replication Connection.
  Perform a manual Sync operation on the Asynchronous session.
• C.Create Replication Interfaces on destination system.
  Establish FC connectivity using the Synchronous FC Ports of each system.
  Perform a manual Sync operation on the Asynchronous session.
• D.Create Replication Interfaces on both systems.
  Establish FC connectivity using the Synchronous FC Ports of each system.
  Run a Verify and Update operation for the Replication Connection

Correct Answer: A

Explanation/Reference:
To fully configure asynchronous replication between systems, you must do each of following:
Configure connectivity for the replication interfaces used by asynchronous replication

- Configure the replication connection between systems
- Configure replication sessions between systems
Note: To fully configure synchronous replication, you must complete each of following:
Configure connectivity for the synchronous replication interfaces

Create the synchronous replication management ports

Configure the replication connection between systems

Configure replication sessions between systems

References: http://www.emc.com/collateral/white-papers/h15088-emc-unity-replication-technologies.pdf (page 18)

Comment: *

Name: *

Email: *

Verification: *

A storage administrator wants to create a series of daily snapshots for an existing critical LUN. How can the snapshots be created?

• A.Snapshot schedules can only be configured within the LUN Creation wizard
• B.From the Pool Properties page, configure the Snapshot schedule
• C.Only manually taken snapshots are supported on existing LUNs
• D.From the LUN Properties page, configure the Snapshot schedule

Correct Answer: B

In addition to being created ahead of time on the Snapshot Schedules page, new snapshots schedules may also be created during the process of creating a new storage resource from within the creation wizard as an alternative to selecting an existing schedule.

Incorrect Answers:
C: In addition to being taken manually, snapshots can also be scheduled to be taken automatically at specific times or frequencies.

Comment: *

Name: *

Email: *

Verification: *

A storage administrator is implementing FAST Cache on a Unity 500 storage array andcan select from a mix of SSD drives. Which drive types can be configured to meet the administrator's requirements?

• A.3.2 TB and 800 GB
• B.1.6 TB and 3.2 TB
• C.400GB and 1.6 TB
• D.200 GB and 400 GB
