The incoming client IP address is 195.64.45.52 and the last five connections have been sent to members A, C, E, D and B. Given the virtual server, pool, and persistence definitions and statistics shown in the above graphic, which member will be used for the next connection?

• A.10.10.20.1:80
• B.10.10.20.2:80
• C.10.10.20.4:80
• D.It cannot be determined with the information given.
• E.10.10.20.3:80
• F.10.10.20.5:80

Comment: *

Name: *

Email: *

Verification: *

How should a BIG-IP Administrator control the amount of traffic that a newly enabled pool member receives.

• A.set the Slow Ramp Time
• B.set a Connection Limit
• C.set the Priority Group Activation
• D.set a Health Monitor

Comment: *

Name: *

Email: *

Verification: *

Which two can be a part of a virtual server's definition. (Choose two.)

• A.monitor(s)
• B.pool(s)
• C.loadElbalancing method(s)
• D.node address(es)
• E.rule(s)

Comment: *

Name: *

Email: *

Verification: *

Assume a BIG-IP has no NATs or SNATs configured. Which two scenarios are possible when client traffic arrives on a BIG-IP that is NOT destined to a self-IP? (Choose two.)

• A.If the destination of the traffic matches a virtual server, the traffic will be forwarded, but it cannot be loadbalanced since no SNAT has been configured.
• B.If the destination of the traffic matches a virtual server, the traffic will be processed per the virtual server definition.
• C.If the destination of the traffic does not match a virtual server, the traffic will be forwarded based on routing tables.
• D.If the destination of the traffic does not match a virtual server, the traffic will be discarded.

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

How many nodes are represented on the network map shown?

• A.One
• B.Three
• C.Four
• D.Two

Comment: *

Name: *

Email: *

Verification: *
