An LTM Specialist with the Administrator role and terminal access of "tmsh" logs in via ssh and is in the Traffic Manager Shell. The LTM Specialist wants to enter the bash shell to review log files.
Which command does the LTM Specialist need to run to access the bash shell?

• A.run /cli bash
• B.run /util bash
• C.exit
• D.quit

Comment: *

Name: *

Email: *

Verification: *

An LTM device has been configured to log the reasons for generating TCP RST packets.
The following log entry occurs:
"01230140:3: RST sent from 192.168.1.100:80 to 192.168.1.124:39272, [0x112d82a:1721] {peer} TCP RST from remote system." Which condition will trigger this log entry?

• A.The LTM device reset the connection because no pool members are available.
• B.The LTM device has reached the maximum number of allowed attempts to send the data segment to the affected TCP connection.
• C.A virtual server connection limit has been reached.
• D.The host at the other end terminated the TCP connection.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit --

-- Exhibit --
Refer to the exhibit.
A company uses a complex piece of client software that connects to one or more virtual servers (VS) hosted on an LTM device. The client software is experiencing issues. An LTM Specialist must determine the cause of the problem.
The LTM Specialist is seeing a client source IP of 168.210.232.5 in the tcpdump. However, the client source IP is actually 10.123.17.12.
Why does the IP address of 10.123.17.12 fail to appear in the tcpdump?

• A.Network Address Translation (NAT) has occurred in the path between the client and the LTM device.
• B.The Secure Network Address Translation (SNAT) pool on the virtual server is activated.
• C.The LTM device performed NAT on the individual's IP address.
• D.The individual's data stream is being routed to the LTM device by a means other than the default route.

Comment: *

Name: *

Email: *

Verification: *

An LTM Specialist needs to modify the logging level for tcpdump execution events. Checking the BigDB Key, the following is currently configured:
sys db log.tcpdump.level {
value "Notice"
}
Which command should the LTM Specialist execute on the LTM device to change the logging level to informational?

• A.tmsh set /sys db log.tcpdump.level value informational
• B.tmsh set /sys db log.tcpdump.level status informational
• C.tmsh modify /sys db log.tcpdump.level status informational
• D.tmsh modify /sys db log.tcpdump.level value informational

Comment: *

Name: *

Email: *

Verification: *

Refer of the exhibit.

The 816-IP Administrator runs the command shown and observes a device trust issue between BIG-IP devices in a device group. The issue prevents config sync on device bigip3.local.
What is preventing the config sync?

• A.Next Active Load factor is 0 on bigip1.local
• B.Both devices are standby
• C.Next Active Load factor is 1 on bigip1.local
• D.Time Delta to local system is 12
