Question 11

The FTP protocol is a protocol based on ______.

A.TCP
B.UDP
C.SSH
D.PX

Question 12

Which of the following options are features of port-based 802.1x authentication?

A.As long as the first user under the port is successfully authenticated, other access users can use network resources without authentication
B.When the first user under the port goes offline, other users will also be denied access to the network
C.When a user goes offline, only that user cannot use the network
D.All access users under the port need to be independently verified

Question 13

The WAN links of the customer's two routers MSR-1 and MSR-2 use the PPP protocol, and MSR-1 is required as the primary verifier to verify MSR-2 through CHAP. Then which of the following configurations may be required for MSR-2? (Multiple choice)

A.[MSR-2-Serial1/0] ip address 10.10.10.1 22
B.[MSR-2]ppp chap user user
C.[MSR-2-Serial1/0] ip address ppp-negotiate
D.[MSR-2]ppp chap password simple password

Question 14

PPP has to go through a series of negotiation process before establishing the link, the correct negotiation sequence is ___. (Fill in the code of each step one by one, there can be no spaces in between, such as: ABC)

A.NCP
B.LCP
C.PAP/CHAP

Question 15

The customer's network structure is shown in the figure.

To achieve the following requirements:
1. Host C and Host B visit each other
2. Host B and Host A cannot visit each other
3. Host A and Host C cannot visit each other
So ______ . (Multiple choice)

A.Apply advanced ACLs on the GE0/0 interfaces of the two routers to achieve this requirement
B.Apply advanced ACL on MSR-1 interface S1/0 and GE0/0 respectively to achieve this requirement
C.Only apply advanced ACL on MSR-1 interface GE0/0 to achieve this requirement
D.Only applying ACL on interface GE0/0 of MSR-1 cannot meet this requirement
