Refer to the exhibit.

An administrator wants to verify the operation of MultiZone in a network. The administrator uses the command show ap debug multizoneto generate the output shown in the exhibit.
Based on the output, which statement is true?

• A.Zone 1 is the primary zone, and zone 0 is the data zone.
• B.The MultiZone APs are in a cluster.
• C.The maximum VAPs in the MultiZone is 15.
• D.The primary zone has limited the data zone to one WLAN.

Comment: *

Name: *

Email: *

Verification: *

In a cluster-controllerenvironment, which Aruba component in a network builds a cache table of mDNS records that can be used to help user devices access Apple Bonjour services?

• A.the Mobility Master and cluster members
• B.the Mobility Master
• C.the Mobility Controllers that arecluster members
• D.any Aruba Mobility Controller

Comment: *

Name: *

Email: *

Verification: *

Which methods can be used to configure RAP redundancy when connected to two redundant Aruba Mobility Controllers (MCs) in the DMZ? (Select two.)

• A.AirWave direction to RAPs redundant Mobility Controllers.
• B.Primary and backup LMS IP addresses.
• C.Virtual IP address of the two controllers.
• D.IPSec High Availability (HA) between two cluster members.
• E.Active and Standby AAC.

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

Two Aruba Mobility Controllers (MC) are managed by a Mobility Master (MM) in a non-cluster deployment as shown in the exhibit.
* The C1 controller is connected to AP1 and AP2.
* The C2controller is connected to AP3 and AP4.
* VLAN mobility is enabled in the VAPs of both AP Groups.
* Both C1 and C2 support the same VLANs.
* User1's wireless device supports BSS Fast Transitioning and is currently connected to AP1.
What happens if User1 roams across the network and the user's device associates to AP3?

• A.User1's traffic is terminated on the C2 controller, and they will have to re-authenticate and can keep their original IP address.
• B.User1's traffic is tunneled to the C1 controller, where they will not have to re-authenticate and can keep their original IP address.
• C.User1's traffic is terminated on the C2 controller, and they will have to re-authenticate and re-obtain a new IP address.
• D.User1's traffic is terminated on the C2 controller, and they will not have to re-authenticate but will need to obtain a new IP address.

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

An administrator supports a RAP at a branch office shown in the exhibit. The company has one Mobility Controller (MC) at the Primary DMZ site and one at the Secondary DMZ site. The RAP is configured to connect to only the MC at the Primary DMZ site. A network outage with the ISP at the Primary DMZ site causes the RAP to reboot. Upon reboot, the RAP cannot build a tunnel to the Secondary DMZ site MC because the administrator forgot to addthe Second LMS IP address to the AP Group configuration. Once the RAP can successfully connect, the administrator can add the Secondary DMZ MC as a backup LMS to fix the AP Group.
What should the administrator implement to allow the RAP to connect tothe MC at the Secondary DMZ site while the outage at the primary site persists?

• A.Dynamic discovery through DHCP Option 43
• B.Dynamic discovery through multicast ADP
• C.Static configuration from apboot mode
• D.Dynamic discovery through DHCP Option 60

Comment: *

Name: *

Email: *

Verification: *
