SNMPv1 defines five protocol operations.

• A.FALSE
• B.TRUE

Comment: *

Name: *

Email: *

Verification: *

The priority of the LAGP protocol is as shown in the figure. Switch A and Switch B adopt link aggregation in LAGP mode, and all interfaces loin the link aggregation group. The maximum number of active ports is set to 3. Which port of switch A is not the active port?

• A.GO/0/3
• B.GO/0/0
• C.GO/0/1
• D.G0/0/2

Comment: *

Name: *

Email: *

Verification: *

Refer to the graphic.

A web server in a private network is required to provide HTTP services to public users. The network administrator is required to configure NAT on RTA. Which configuration should be used?

• A.[RTA-Serial0/0/1]nat server protocol tcp global 192.168.1.1 www.inside 202.10.10.1 8080
• B.[RTA-Serial1/0/1]nat server protocol tcp global 202.10.10.1 www.inside 192.168.1.1 8080
• C.[RTA-Gigabitethernet0/0/1]nat server protocol tcp global 192.168.1.1 www.inside 202.10.10.1 8080
• D.[RTA-Gigabitethernet0/0/1]nat server protocol tcp global 202.10.10.1 www.inside 192.168.1.1 8080

Comment: *

Name: *

Email: *

Verification: *

Which username and password will be used by the peer router to perform PPP link authentication? aaa local-user test password cipher test local-user test service-type ppp local-user test1 password cipher test1 local-user test1 service-type telnet local-user test2 password cipher test2
#
interface Serial1/0/0 link-protocol ppp
ppp authentication-mode chap
ip address 10.0.12.1 255.255.255.0

• A.user name:test2 Password: test
• B.user name:test2 Password: test2
• C.user name:test1 Password: test1
• D.user name:test Password: test

Comment: *

Name: *

Email: *

Verification: *

<Huawei> system-view
[Huawei]command-privilege level 3 view user save
Refer to the command output. What is the result of the shown command?

• A.The command adjusts the user view command privilege level to 3, and saves the configuration.
• B.The command adjusts the save command of a user to privilege level 3.
• C.The command adjusts the save command in the user view to privilege level 3.
• D.The command adjusts the privilege level of a user to 3, and saves the configuration.
