Click the Exhibit button.

You are asked to look at a configuration that is designed to take all traffic with a specific source IP address and forward the traffic to a traffic analysis server for further evaluation. The configuration is not working as intended.
Referring to the exhibit, which change must be made to correct the configuration?

• A.Apply the filter as an output filter on interface xe-0/1/0.0
• B.Apply the filter as an input filter on interface xe-0/2/1.0
• C.Apply the filter as an input filter on interface xe-0/0/1.0
• D.Create a routing instance named default

Comment: *

Name: *

Email: *

Verification: *

You are asked to configure a new SRX Series CPE device at a remote office. The device must participate in forwarding MPLS and IPsec traffic.
Which two statements are true regarding this implementation? (Choose two.)

• A.A firewall filter must be configured to enable packet mode forwarding
• B.Host inbound traffic must be processed by the flow module
• C.The SRX Series device can process both MPLS and IPsec with default traffic handling
• D.Host inbound traffic must not be processed by the flow module

Comment: *

Name: *

Email: *

Verification: *

You have designed the firewall filter shown in the exhibit to limit SSH control traffic to yours SRX Series device without affecting other traffic.
Which two statement are true in this scenario? (Choose two.)

• A.The filter should be applied as an output filter on the loopback interface.
• B.Applying the filter will achieve the desired result.
• C.Applying the filter will not achieve the desired result.
• D.The filter should be applied as an input filter on the loopback interface.

Comment: *

Name: *

Email: *

Verification: *

You have set up Security Director with Policy Enforcer and have configured 12 third-party feeds and a Sky ATP feed. You are also injecting 16 feeds using the available open API. You want to add another compatible feed using the available open API, but Policy Enforcer is not receiving the new feed.
What is the problem in this scenario?

• A.You cannot add more than 16 feeds through the available open API
• B.You cannot add more than 16 feeds with the available open API
• C.You must wait 48 hours for the feed to update
• D.You have reached the maximum limit of 29 total feeds

Comment: *

Name: *

Email: *

Verification: *

Click the Exhibit button.

Referring to the exhibit, you are attempting to enable IPsec power mode to improve IPsec VPN performance. However, you are unable to use IPsec power mode.
What is the problem?

• A.IPsec power mode cannot be used with high IPsec maximum segment size values
• B.IPsec power mode cannot be used with advanced services
• C.IPsec power mode requires that you configure a policy-based VPN
• D.IPsec power mode cannot be used with IPsec performance acceleration
