Which of the following statements about a Segment Routing SID is FALSE?

• A.A Node-SID is usually associated with a router's system interface.
• B.Adjacency-SID values are taken from the SRGB configured for the routing protocol.
• C.A Prefix-SID can be configured directly as a label value or indirectly as an index.
• D.An Adjacency-SID does not have to be configured.

Comment: *

Name: *

Email: *

Verification: *

OSPF is being used for segment routing with traffic-engineering (SR-TE). The traffic-engineering option has been set to "sr-te false". Which of the following statements is TRUE?

• A.The TE information will be advertised for all the OSPF links that have MPLS enabled.
• B.The TE information will only be advertised using application-specific sub-TLVs.
• C.The TE information will only be advertised for the OSPF links that have both MPLS and RSVP enabled.
• D.The TE information will only be advertised using extended-link opaque LSAs.

Comment: *

Name: *

Email: *

Verification: *

An SR-TE LSP with a path definition that includes router R4 as a loose hop and for which Seamless-BFD has been enabled is following the path shown in the exhibit. What happens after router R4 fails if the routers along the path follow the default behavior?

• A.The head end will periodically try to calculate a new path at a rate defined by the retry timer.
• B.The head end will periodically try to calculate a new path at a rate defined by the resignal timer.
• C.The head end will continue forwarding traffic to the current next-hop indefinitely, which will be discarded at the point of failure.
• D.The head end will continue forwarding traffic to the current next-hop indefinitely, and R2 will redirect the traffic to R3 after IGP reconvergence.

Comment: *

Name: *

Email: *

Verification: *

Which of the following statements about segment routing fast re-route is FALSE?

• A.Fast re-route is a temporary fix that becomes active for a short period of time after a local network failure.
• B.Fast re-route typically protects the active segment of a tunnel, but under certain conditions it can protect an end-to-end multi-segment tunnel instead.
• C.On a Nokia 7750 SR, R-LFA and TI-LFA can be enabled independently of each other.
• D.The parameter "max-sr-frr-labels" limits the number of labels that R-LFA can add to the data packet encapsulation.

Comment: *

Name: *

Email: *

Verification: *

Which of the following is NOT one of the main goals of traffic engineering?

• A.Utilizing redundant links.
• B.Avoiding potential congestion points in the network.
• C.Defining traffic paths based on various constraints.
• D.Using the shortest possible path through the network to the destination.
