An aerospace engineering company recently adopted a hybrid cloud infrastructure with AWS. One of the Solutions Architect's tasks is to launch a VPC with both public and private subnets for their EC2 instances as well as their database instances.
Which of the following statements are true regarding Amazon VPC subnets? (Select TWO.)

• A.Every subnet that you create is automatically associated with the main route table for the VPC.
• B.The allowed block size in VPC is between a /16 netmask (65,536 IP addresses) and /27 netmask (32 IP addresses).
• C.Each subnet spans to 2 Availability Zones.
• D.Each subnet maps to a single Availability Zone.
• E.EC2 instances in a private subnet can communicate with the Internet only if they have an Elastic IP.

Correct Answer: A,D

A VPC spans all the Availability Zones in the region. After creating a VPC, you can add one or more subnets in each Availability Zone. When you create a subnet, you specify the CIDR block for the subnet, which is a subset of the VPC CIDR block. Each subnet must reside entirely within one Availability Zone and cannot span zones. Availability Zones are distinct locations that are engineered to be isolated from failures in other Availability Zones. By launching instances in separate Availability Zones, you can protect your applications from the failure of a single location.

Below are the important points you have to remember about subnets:
- Each subnet maps to a single Availability Zone.
- Every subnet that you create is automatically associated with the main route table for the VPC.
- If a subnet's traffic is routed to an Internet gateway, the subnet is known as a public subnet.
The option that says: EC2 instances in a private subnet can communicate with the Internet only if they have an Elastic IP is incorrect. EC2 instances in a private subnet can communicate with the Internet not just by having an Elastic IP, but also with a public IP address via a NAT Instance or a NAT Gateway. Take note that there is a distinction between private and public IP addresses. To enable communication with the Internet, a public IPv4 address is mapped to the primary private IPv4 address through network address translation (NAT).
The option that says: The allowed block size in VPC is between a /16 netmask (65,536 IP addresses) and /27 netmask (32 IP addresses) is incorrect because the allowed block size in VPC is between a /16 netmask (65,536 IP addresses) and /28 netmask (16 IP addresses) and not /27 netmask.
The option that says: Each subnet spans to 2 Availability Zones is incorrect because each subnet must reside entirely within one Availability Zone and cannot span zones. References:
https://docs.aws.amazon.com/AmazonVPC/latest/UserGuide/VPC_Subnets.html
https://docs.aws.amazon.com/vpc/latest/userguide/vpc-ip-addressing.html Check out this Amazon VPC Cheat Sheet: https://tutorialsdojo.com/amazon-vpc/ Tutorials Dojo's AWS Certified Solutions Architect Associate Exam Study Guide:
https://tutorialsdojo.com/aws-certified-solutions-architect-associate/

Comment: *

Name: *

Email: *

Verification: *

A financial company wants to store their data in Amazon S3 but at the same time, they want to store their frequently accessed data locally on their on-premises server. This is due to the fact that they do not have the option to extend their on-premises storage, which is why they are looking for a durable and scalable storage service to use in AWS.
What is the best solution for this scenario?

• A.Use Amazon Glacier.
• B.Use the Amazon Storage Gateway - Cached Volumes.
• C.Use a fleet of EC2 instance with EBS volumes to store the commonly used data.
• D.Use both Elasticache and S3 for frequently accessed data.

Comment: *

Name: *

Email: *

Verification: *

A news company is planning to use a Hardware Security Module (CloudHSM) in AWS for secure key storage of their web applications. You have launched the CloudHSM cluster but after just a few hours, a support staff mistakenly attempted to log in as the administrator three times using an invalid password in the Hardware Security Module. This has caused the HSM to be zeroized, which means that the encryption keys on it have been wiped. Unfortunately, you did not have a copy of the keys stored anywhere else.
How can you obtain a new copy of the keys that you have stored on Hardware Security Module?

• A.Restore a snapshot of the Hardware Security Module.
• B.Use the Amazon CLI to get a copy of the keys.
• C.The keys are lost permanently if you did not have a copy.
• D.Contact AWS Support and they will provide you a copy of the keys.

Correct Answer: C

Attempting to log in as the administrator more than twice with the wrong password zeroizes your HSM appliance. When an HSM is zeroized, all keys, certificates, and other data on the HSM is destroyed. You can use your cluster's security group to prevent an unauthenticated user from zeroizing your HSM.

Amazon does not have access to your keys nor to the credentials of your Hardware Security Module (HSM) and therefore has no way to recover your keys if you lose your credentials. Amazon strongly recommends that you use two or more HSMs in separate Availability Zones in any production CloudHSM Cluster to avoid loss of cryptographic keys.
Refer to the CloudHSM FAQs for reference:
Q: Could I lose my keys if a single HSM instance fails?

Comment: *

Name: *

Email: *

Verification: *

A company has hired a solutions architect to design a reliable architecture for its application. The application consists of one Amazon RDS DB instance and two manually provisioned Amazon EC2 instances that run web servers. The EC2 instances are located in a single Availability Zone.
An employee recently deleted the DB instance, and the application was unavailable for 24 hours as a result.
The company is concerned with the overall reliability of its environment.
What should the solutions architect do to maximize reliability of the application's infrastructure?

• A.Delete one EC2 instance and enable termination protection on the other EC2 instance. Update the DB instance to be Multi-AZ, and enable deletion protection.
• B.Update the DB instance to be Multi-AZ, and enable deletion protection. Place the EC2 instances behind an Application Load Balancer, and run them in an EC2 Auto Scaling group across multiple Availability Zones.
• C.Create an additional DB instance along with an Amazon API Gateway and an AWS Lambda function.
  Configure the application to invoke the Lambda function through API Gateway. Have the Lambda function write the data to the two DB instances.
• D.Place the EC2 instances in an EC2 Auto Scaling group that has multiple subnets located in multiple Availability Zones. Use Spot Instances instead of On-Demand Instances. Set up Amazon CloudWatch alarms to monitor the health of the instances. Update the DB instance to be Multi-AZ, and enable deletion protection.

Comment: *

Name: *

Email: *

Verification: *

A company has an on-premises application that generates a large amount of time-sensitive data that is backed up to Amazon S3. The application has grown and there are user complaints about internet bandwidth limitations. A solutions architect needs to design a long-term solution that allows for both timely backups to Amazon S3 and with minimal impact on internet connectivity for internal users.
Which solution meets these requirements?

• A.Establish AWS VPN connections and proxy all traffic through a VPC gateway endpoint
• B.Establish a new AWS Direct Connect connection and direct backup traffic through this new connection.
• C.Order daily AWS Snowball devices Load the data onto the Snowball devices and return the devices to AWS each day.
• D.Submit a support ticket through the AWS Management Console Request the removal of S3 service limits from the account.
