Refer to the exhibits.


A storage network engineer activates a zoneset on MDS-A and verifies the successful activation (Exhibit 1).
The engineer is then notified that there is a SAN outage (Exhibit 2) What is the cause of the outage?

• A.Another network engineer activated the zoneset ZoneSetMDS-B-VSAN100 command on another switch in the fabric.
• B.Another network engineer activated zoneset ZoneSetMDS-B-VSAN100 on MDS-A.
• C.Another network engineer issued the zone default-zone permit vsan 100 command on another switch in the fabric.
• D.Another network engineer issued the zone mode enhanced vsan 100 command on another switch in the fabric.

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

Refer to the exhibit. Which configuration change improves the ability of the link to recover from frame loss?

• A.Enable selective acknowledgment.
• B.Increase the send buffer size to 15000 KB.
• C.Disable PMTU discovery.
• D.Increase the reset timeout.

Comment: *

Name: *

Email: *

Verification: *

After a subordinate switch requests a domain ID form a principal switch, the requested domain ID becomes the runtime domain ID, and all interfaces on the affected VSAN are isolated. What is a solution to the issue?

• A.Add the received ID to the allowed list.
• B.Configure IVR NAT on the affected VSAN.
• C.Configure a static domain on the subordinate switch and reboot the switch.
• D.Enable the FICON feature on the affected VSAN.

Comment: *

Name: *

Email: *

Verification: *

Which result occurs if a device alias is renamed and then the original device alias name is used in an add command in the same session?

• A.The rename command is moved to the rejected list and the add command executes successfully.
• B.Both commands execute successfully.
• C.The device alias is renamed and the add command is moved to the rejected list.
• D.Both commands are moved to the rejected list.

Comment: *

Name: *

Email: *

Verification: *

Which two tools are included in Cisco Prime DCNM for SAN? (Choose two.)

• A.Cisco DCNM-SAN Client
• B.Cisco Security Manager
• C.Device Discovery
• D.Cisco DCNM-LAN server
• E.Cisco Traffic Analyzer
