Which of the following allows for the interception of traffic between the source and destination?

• A.Self-signed certificate
• B.VLAN hopping
• C.On-path attack
• D.Phishing

Comment: *

Name: *

Email: *

Verification: *

After a recent power outage, users are reporting performance issues accessing the application servers.
Wireless users are also reporting intermittent Internet issues.
INSTRUCTIONS
Click on each tab at the top of the screen. Select a widget to view information, then use the drop-down menus to answer the associated questions. If at any time you would like to bring back the initial state of the simulation, please click the Reset All button.

Correct Answer:

See the answer and solution below.
Explanation:
Network Health:
WAN 2 appears to have a lower average latency and loss percentage, which would make it the preferred WAN station for VoIP traffic. VoIP traffic requires low latency and packet loss to ensure good voice quality and reliability. WAN 1 seems to have higher RAM and processor usage, which could also affect the performance of VoIP traffic.
Here's the summary of the key metrics for WAN 1 and WAN 2 from the image provided:
* WAN 1:
* Uplink Speed: 10G
* Total Usage: 26.969GB Up / 1.748GB Down
* Average Throughput: 353MBps Up / 23.42MBps Down
* Loss: 2.51%
* Average Latency: 24ms
* Jitter: 9.5ms
* WAN 2:
* Uplink Speed: 1G
* Total Usage: 930GB Up / 138GB Down
* Average Throughput: 12.21MBps Up / 1.82MBps Down
* Loss: 0.01%
* Average Latency: 11ms
* Jitter: 3.9ms
For VoIP traffic, low latency and jitter are particularly important to ensure voice quality. While WAN 1 has higher bandwidth and throughput, it also has higher latency and jitter compared to WAN 2. However, WAN 2 has much lower loss, lower latency, and lower jitter, which are more favorable for VoIP traffic that is sensitive to delays and variation in packet arrival times.
Given this information, WAN 2 would generally be preferred for VoIP traffic due to its lower latency, lower jitter, and significantly lower loss percentage, despite its lower bandwidth compared to WAN 1. The high bandwidth of WAN 1 may be more suitable for other types of traffic that are less sensitive to latency and jitter, such as bulk data transfers.

Device Monitoring:
the device that is experiencing connectivity issues is the APP Server or Router 1, which has a status of Down.
This means that the server is not responding to network requests or sending any data. You may want to check the physical connection, power supply, and configuration of the APP Server to troubleshoot the problem.

Comment: *

Name: *

Email: *

Verification: *

A network administrator is deploying a new switch and wants to make sure that the default priority value was set for a spanning tree. Which of the following values would the network administrator expect to see?

• A.4096
• B.8192
• C.32768
• D.36684

Comment: *

Name: *

Email: *

Verification: *

Which of the following standards enables the use of an enterprise authentication for network access control?

• A.802.1Q
• B.802.1X
• C.802.3bt
• D.802.11h

Comment: *

Name: *

Email: *

Verification: *

In an environment with one router, which of the following will allow a network engineer to communicate between VLANs without purchasing additional hardware?

• A.Subinterfaces
• B.VXLAN
• C.Layer 3 switch
• D.VIR
