An LTM Specialist configures two LTM devices in a high-availability pair with trusts established and device groups configured properly using network failover. After several months, the LTM Specialist notices that changes made to one LTM device do NOT cause the synchronization status to update to "changes pending," and this device does NOT synchronize with the device group.
Which two steps should the LTM Specialist take to identify the issue? (Choose two.)

• A.Verify that NTP is synchronized.
• B.Verify the network connectivity between the devices.
• C.Verify that the devices are not using self-signed certificates.
• D.Verify that port lockdown on the ConfigSync interface is set to allow port 1026.
• E.Verify that ConfigSync is using the management IP address.

Comment: *

Name: *

Email: *

Verification: *

An LTM device has been configured to log the reasons for generating TCP RST packets.
The following log entry occurs:
"01230140:3: RST sent from 192.168.1.100:80 to 192.168.1.124:39272, [0x112d82a:1721] {peer} TCP RST from remote system."
Which condition will trigger this log entry?

• A.A virtual server connection limit has been reached.
• B.The LTM device reset the connection because no pool members are available.
• C.The LTM device has reached the maximum number of allowed attempts to send the data segment to the affected TCP connection.
• D.The host at the other end terminated the TCP connection.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit --
Refer to the exhibit.
A client attempts to connect from a Google Chrome browser to a virtual server on a BIG-IP LTM. The virtual server is SSL Offloaded. When the client connects, the client receives an SSL error. The client receives the same errors when trying Mozilla Firefox and Internet Explorer browsers.
The LTM Specialist does an ssldump on the virtual server and receives the results as per the exhibit.
How should this be resolved?

• A.Select the appropriate "SSL Profile (Client)" in the virtual server settings.
• B.Set the virtual server to listen on port 443 (HTTPS).
• C.Upgrade the client to support the appropriate SSL cipher suite.
• D.Adjust the SSL key length in the SSL profile to match the minimum required by the client.

Comment: *

Name: *

Email: *

Verification: *

Which command line interface command will check if the BIG-IP platform contains a packet velocity ASIC (PVA)?

• A.bigpipe platform show | grep -i pva
• B.tmsh show /sys hardware pva status
• C.tmsh show /sys hardware | grep -i pva
• D.tmsh show /ltm hardware | grep -i pva

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit - -- Exhibit -

Refer to the exhibits.
Which two servers are missing two frequently used URLs? (Choose two.)

• A.172.16.20.2 /text.one /text.txt
• B.172.16.20.1 /text.one /text.txt
• C.172.16.20.1 /text.txt /browserspecific.html
• D.172.16.20.2 /text.one /browserspecific.html
• E.172.16.20.3 /text.one /browserspecific.html
