Question 91
In BGP routing optimization, for the following four attributes, the order of consideration by the system is _______.
1. MED
2. Orign
3. As-path
4. Local preference
Question 92
A network is connected to the Internet through a 64kbps wide area link. The customer requires that the bandwidth of this link is used as efficiently as possible.
You should use _______ to connect to the Internet.
Question 93
In the topology shown in the figure, the following configurations are performed on RTA and RTB respectively:
RTA]ospf 1
RTA-ospf-1]area 1
RTA-ospf-1-area-0.0.0.1]network 1.1.1.1 0.0.0.0
RTA-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
RTA-ospf-1-area-0.0.0.1]network 192.168.1.0 0.0.0.255
RTA-ospf-1-area-0.0.0.1]network 192.168.4.0 0.0.0.255
RTA-ospf-1-area-0.0.0.1]network 192.168.7.0 0.0.0.127
RTA-ospf-1-area-0.0.0.1]network 192.168.8.0 0.0.0.127
RTA-ospf-1-area-0.0.0.1]network 192.168.15.0 0.0.0.255
RTB]ospf 1
RTB-ospf-1]area 1
RTB-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
RTB-ospf-1-area-0.0.0.1]area 0
RTB-ospf-1-area-0.0.0.1]abr-summar192.168.0.0 255.255.252.0 not-advertise
Then which of the following routes may exist in the RTC routing table_____
Question 94
Run the command on the router and its display information as follows:
<RTA>displaisis peer
Peer information for ISIS(1)
----------------------------
Stem Id: 2222.2222.2222
Interface: Eth0/0 Circuit Id:
State: Up HoldTime: 27s Tpe: L1 PRI: 16
Stem Id: 3333.3333.3333
Interface: Tun3 Circuit Id:
State: Up HoldTime: 25s Tpe: L2 PRI: -
From the above information, you can know RTA______.
Question 95
In the topology shown in the figure, the following configurations are performed on RTA, RTB, RTC and RTD:
RTA-LoopBack0] ip address 1.1.1.1 255.255.255.255
RTA]ospf 1
RTA-ospf-1]area 1
RTA-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
RTA-ospf-1]import-route direct
RTB-LoopBack0] ip address 2.2.2.2 255.255.255.255
RTB]ospf 1
RTB-ospf-1]area 1
RTB-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
RTB-ospf-1-area-0.0.0.1]area 0
RTB-ospf-1-area-0.0.0.0]network 2.2.2.2 0.0.0.0
RTB-ospf-1-area-0.0.0.0]network 20.0.0.0 0.0.0.255
RTC-LoopBack0] ip address 3.3.3.3 255.255.255.255
RTC]ospf 1
RTC-ospf-1]area 0
RTC-ospf-1-area-0.0.0.0]network 20.0.0.0 0.0.0.255
RTC-ospf-1-area-0.0.0.0]area 2
RTC-ospf-1-area-0.0.0.2]nssa default-route-advertise no-summarRTC-ospf-1-area-0.0.0.2]network
30.0.0.0 0.0.0.255
RTC-ospf-1]import-route direct
RTD-LoopBack0] ip address 4.4.4.4 255.255.255.255
RTD]ospf 1
RTD-ospf-1]area 2
RTD-ospf-1-area-0.0.0.2]network 30.0.0.0 0.0.0.255
RTD-ospf-1-area-0.0.0.2]nssa
RTD-ospf-1]import-route direct
Which of the following routes may exist in the RTD routing table _______.
