A customer has received a second frame for their HPE Synergy environment. The customer has added the second frame to the rack and correctly cabled the power and management ring.
Based on the design shown, which changes need to be made to the configuration to ensure high availability? (Choose two.)

• A.Split the management uplinks across both frames
• B.Configure high availability in vCenter for the HPE OneView appliance
• C.Configure high availability on the Frame Link Modules
• D.Enable high availability in the Settings of the Composer
• E.Move one of the Composers to the second frame

Comment: *

Name: *

Email: *

Verification: *

A customer is planning an HPE Synergy solution with 20 frames and needs to minimize the number of management ports that are required to connect the frames into the existing management network.
Which procedure should the integrator use to address the customer's concern?

• A.Connect the RJ-45 front ports of each frame to an external switch. Then, connect the uplink from the external switch into the customer's management network.
• B.Connect FLMs from all frames into a management ring. Then, connect the management ring to the customer's management network using two uplinks.
• C.Connect FLMs from all frames to two external switches for redundancy. Then, connect the two uplinks from the two switches into the customer's management network.
• D.Connect the RJ-45 front ports of each frame to two external switches for redundancy. Then, connect the uplink from the two switches into the customer's management network.

Comment: *

Name: *

Email: *

Verification: *

How can an integrator use an HPE Synergy D3940 storage module to provision shared storage to compute modules without requiring a separate SAN to be connected to the frame?

• A.Configure drives as DAS storage, and use Image Streamer to present the disks as iSCSI targets to the whole frame.
• B.Configure drives as SAN storage, and configure a Smart Array P416ie-m Controller into HBA mode. Add the SAN disk to the server profile.
• C.Configure drives as DAS storage, and use StoreVirtual VSA to present the disks as iSCSI storage to the whole frame.
• D.Configure drives as SAN storage, and configure a P240nr array controller into HBA mode. Add the SAN disk to the server profile.

Comment: *

Name: *

Email: *

Verification: *

A customer is planning to deploy OneView for vCenter Server to improve management procedures for growing virtualization environment. The customer is concerned about resources required by HPE OneView for vCenter Server.
Which statement about deploying HPE OneView for vCenter Server is true?

• A.It is deployed as an application on the Windows Server machine with at least 48GB of memory.
• B.It is deployed as a part of the HPE Composer installation.
• C.It can only be deployed if HPE Global Dashboard is already installed.
• D.It is deployed as a virtual machine on the supported hypervisor.

Comment: *

Name: *

Email: *

Verification: *

An HPE Synergy compute module has a template-based server profile with two identically configured connections, each containing five VLANs.What is the most efficient method the integrator can use to add a new VLAN to each connection?

• A.Add the new VLAN to the network set configured in the profile template, and update the server profile from the template
• B.Add the new VLAN under Edit server profile connections
• C.Add the new VLAN under Edit server profile connections in the profile template, and update the server profile from the template
• D.Add the new VLAN to the network set configured in the profile template
