Examine the attached diagram

Two AOS-CX switches are configured for VSX at the access layer, where servers attached to them. An SVI interface is configured for VLAN 10 and serves as the default gateway for VLAN 10. The ISL link between the switches fails, but the keepalive interface functions. Active gateway has been configured on the switches.
What is correct about access from the servers to the Core?

• A.Server 2 cannot access the core layer.
• B.Server 2 can successfully access the core layer via the keepalive link.
• C.Server 1 can access the core layer via both uplinks.
• D.Server 1 and Server 2 can communicate with each other via the core layer.

Comment: *

Name: *

Email: *

Verification: *

A company requires access by all users, guests, and employees to be authenticated. Employees will be authenticated using 802.1X, whereas guests will be authenticated using captive portal. Which type of authentication must be configured on an AOS-CX switch ports where both guests and employees connect?

• A.802.1X, captive portal, and MAC-Auth
• B.Both 802.1X and captive portal
• C.Both 802.1X and MAC-Auth
• D.802.1X only

Comment: *

Name: *

Email: *

Verification: *

A network administrator needs to replace an antiquated access layer solution with a modular solution involving AOS-CX switches The administrator wants to leverage virtual switching technologies. The solution needs to support high-availability with dual-control planes Which solution should the administrator implement?

• A.AOS-CX 6300
• B.AOS-CX S400
• C.AOS-CX 6400
• D.AOS-CX 8325

Comment: *

Name: *

Email: *

Verification: *

An administrator is looking for a data center switching solution that will greatly reduce the likelihood of dropped frames when uplink congestion is experienced. Which AOS-CX switch queuing feature meets the administrator's needs?

• A.VOQ
• B.FIFO
• C.DWWR
• D.WFQ

Comment: *

Name: *

Email: *

Verification: *

Which concept is implemented using Aruba's dynamic segmentation?

• A.Zero Touch Provisioning
• B.Colorless port
• C.Device fingerprinting
• D.Root of trust
