Referring to the exhibit, which path would traffic passing through R1 take to get to R6?

• A.R1 -> R2 -> R4 -> R6
• B.R1 -> R2 -> R3 -> R6
• C.R1 -> R3 -> R5 -> R6
• D.R1 -> R3 -> R4 -> R6

Comment: *

Name: *

Email: *

Verification: *

Referring to the exhibit, there is a Layer 3 VPN setup that connects sites CE-A-1, CE-A-2, and CE-A-3 together. Host-1 can communicate with Host-3, but Host-1 cannot communicate with Host-2.
What must you do to solve the problem?

• A.Use the auto-exportcommand in both routing instances.
• B.Change the route distinguisher in both routing instances to the same value.
• C.Use BGP instead of static routing between the CE and PE devices.
• D.Use the next-tableconfiguration statement for static routes in the corresponding routing instances.

Comment: *

Name: *

Email: *

Verification: *

You are troubleshooting a problem with a BGP peer where BGP routes are not being accepted from that peer.
Referring to the exhibit, which two statements are correct? (Choose two.)

• A.The reject at the end of the policy is preventing the routes from being accepted.
• B.You cannot have terminating actions outside of terms.
• C.Term 0 is missing a route-filter that specifies the allowed routes.
• D.Term 0 is missing a terminating action that allows BGP routes to be accepted.

Comment: *

Name: *

Email: *

Verification: *

You must deploy an interprovider VPN option that ensures that the ASBRs do not need to store any VPN routes.
In this scenario, which interprovider VPN option should you choose?

• A.option D
• B.option B
• C.option C
• D.option A

Comment: *

Name: *

Email: *

Verification: *

Exhibit:

R1 assigns incoming voice traffic to the ef forwarding class. All other traffic is assigned to the best-effort forwarding class You have configured a CoS re-write rule on R1 to include the correct CoS bit values in packets sent towards R2 You want R2 to classify traffic using the CoS markings created by R1.
Which two configuration steps are necessary to accomplish this task? (Choose two.)

• A.Configure a CoS re-write rule on R2 and assign matching CoS values.
• B.Assign the CoS re-write rule to the ge-0/0/1.0 interface on R2.
• C.Assign the behavior aggregate classifier to the ge-0/0/1.0 interface on R2.
• D.Configure a behavior aggregate classifier on R2.
