You host a multitenant data center that runs VMware. You must perform deep packet inspection on all inter-tenant traffic that is flowing between the VMs within the same hypervisor. Your solution must provide the security services without needing to leave the physical device.
In this scenario, what should you do to solve this problem?

• A.Use a vMX device to isolate each tenant's network and use firewall filters to evaluate inter-tenant traffic.
• B.Use VLANs to isolate each tenant's networks and use an SRX Series device to evaluate inter-tenant traffic.
• C.Use a VLANs to isolate each tenant's network and use IP tables to evaluates inter-tenant traffic.
• D.Use separate vswitches to isolate each-tenant's network and use and use a vSRX device to evaluate inter-tenant traffic.

Comment: *

Name: *

Email: *

Verification: *

In the exhibit, VM1 is part of the same VXLAN segment as VM3.

Which type of message will VTEP B initially send to the RP so that VM3 can communicate with VM1?

• A.PIM register message
• B.IGMP Join (*, G)
• C.PIM join
• D.IGMP Join (S,G)

Comment: *

Name: *

Email: *

Verification: *

Your manager asks you to secure ARP and DHCP traffic across your local Ethernet links In this scenario, which technology will accomplish this task?

• A.A firewall filter
• B.SSL
• C.MAC sec
• D.IPsec

Comment: *

Name: *

Email: *

Verification: *

Which two statements describe an IP fabric? (Choose two.)

• A.xSTP protocols should be used to prevent loops.
• B.Traffic should always follow a single path.
• C.Each leaf should have a connection to each spine.
• D.Open standards allow for vendor interoperability.

Comment: *

Name: *

Email: *

Verification: *

You are logged in to Leaf 1. When examining the routing table, you notice that you have no routes from Leaf 2.

Referring to the exhibit, which two commands would you use to troubleshoot the problem? (Choose two.)

• A.From Spine 1, issue the show route advertising-protocol bgp 172.16.1.2command.
• B.From Leaf 2, issue the show route advertising-protocol bgp 172.16.1.2command.
• C.From Leaf 1, issue the show route receive-protocol bgp 172.16.1.1command.
• D.From Spine 1, issue the show route advertising-protocol bgp 172.16.1.1command.
