Refer to the exhibits.

Phase-3 tunnels cannot be established between spoke-to-spoke in DMVPN. Which two commands are missing? (Choose two.)

• A.The ip nhrp map command is missing on the hub router.
• B.The ip nhrp shortcut command is missing on the spoke routers.
• C.The ip nhrp shortcut commands is missing on the hub router.
• D.The ip nhrp redirect commands is missing on the hub router.
• E.The ip nhrp redirect command is missing on the spoke routers.

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit. What does the imp-null tag represent in the MPLS VPN cloud?

• A.Pop the label
• B.Impose the label
• C.Include the EXP bit
• D.Exclude the EXP bit

Comment: *

Name: *

Email: *

Verification: *

Exhibit:

Bangkok is using ECMP to reach to the 192.168.5.0/24 network. The administrator must configure Bangkok in such a way that Telnet traffic from 192.168.3.0/24 and192.168.4.0/24 networks uses the HongKong router as the preferred router. Which set of configurations accomplishes this task?

• A.access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255
  !
  route-map PBR1 permit 10
  match ip address 101
  set ip next-hop 172.18.1.2
  interface Ethernet0/3
  ip policy route-map PBR1
• B.access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23 access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23
  !
  route-map PBR1 permit 10
  match ip address 101
  set ip next-hop 172.18.1.2
  interface Ethernet0/1
  ip policy route-map PBR1
• C.access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23 access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23
  !
  route-map PBR1 permit 10
  match ip address 101
  set ip next-hop 172.18.1.2
  !
  interface Ethernet0/3
  ip policy route-map PBR1
• D.access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255
  !
  route-map PBR1 permit 10
  match ip address 101
  set ip next-hop 172.18.1.2
  !
  interface Ethernet0/1
  ip policy route-map PBR1

Comment: *

Name: *

Email: *

Verification: *

Drag and Drop the IPv6 First-Hop Security features from the left onto the definitions on the right.

Correct Answer:

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

After applying IPsec, the engineer observed that the DMVPN tunnel went down, and both spoke-to-spoke and hub were not establishing. Which two actions resolve the issue? (Choose two.)

• A.Change the mode from mode tunnel to mode transport on R3.
• B.Configure the crypto isakmp key cisco address 0.0.0.0 on R2 and R3.
• C.Remove the crypto isakmp key cisco address 10.1.1.1 on R2 and R3.
• D.Configure the crypto isakmp key cisco address 192.1.1.1 on R2 and R3.
• E.Change the mode from mode transport to mode tunnel on R2.
