Refer to the exhibit.

The vPC neighborship between two switches is in suspended state. Which configuration change resolves the issue and brings up the vPC neighborship?

• A.Configure QoS MTU value of 9216 on the peer switch
• B.Change STP Port Type to Network on the peer switch
• C.Add VLAN 400-401 to the configuration on the local switch
• D.Enable Bridge Assurance on the local switches

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

The script fails to bring up Ethernet 1/2 when Ethernet 1/1 goes down. Which change enables the script to run as intended?

• A.Include an action to manually shut down Ethernet 1/1
• B.Set the port VLAN
• C.Add an action to configure the terminal
• D.Configure an enable action

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

An engineer configures the server port on a Cisco Nexus 5000 Series Switch. The switch connects to an NPV edge switch port. The server fails to send the FC traffic to the fabric. Which action resolves the issue?

• A.Match the VSAN membership on both ends of the connection.
• B.Enable the NPIV mode on the Cisco Nexus 5000 switch.
• C.Replace the SFP in slot fc2/12.
• D.Configure the BB_credit buffer on the uplink port.

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

A network engineer traces the packet flow from the Veth991 of a blade server toward the core switch. The switch reports performance issues What is the role of the interface Etht/7?

• A.IOM host interface
• B.server interface
• C.fabric interconnect uplink interface
• D.IOM network interface

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit. Sw1 and Sw2 are two Cisco Nexus 9000 Series Switches that run Cisco NX-OS. They are VTEPs in the same vPC domain. Which statement describes what happens in this scenario?

• A.Sw1 drops all traffic because there is no (S, G) OIF list to encapsulate VXLAN multicast packets and send them out to the underlay network through the uplink interfaces.
• B.Sw1 performs the VxLAN multicast encapsulation and decapsulation for all traffic associated with the VxLAN VNIs.
• C.Sw1 and switch 2 perform the VxLAN multicast encapsulation and decapsulation for all traffic associated with the VxLAN VNIs, depending on the hashing.
• D.Sw2 did not send an IP PIM register to the rendezvous point for the multicast group of the VXLAN VNI.
