How does Protocol Independent Multicast function?

• A.In sparse mode it establishes neighbor adjacencies and sends hello messages at 5-second intervals.
• B.It uses the multicast routing table to perform the multicast forwarding function.
• C.It uses unicast routing information to perform the multicast forwarding function.
• D.It uses broadcast routing information to perform the multicast forwarding function.

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

Which type of antenna is show on the radiation patterns?

• A.Dipole
• B.Yagi
• C.Patch
• D.Omnidirectional

Correct Answer: A

Explanation
A dipole antenna most commonly refers to a half-wavelength (/2) dipole. The physical antenna (not the package that it is in) is constructed of conductive elements whose combined length is about half of a wavelength at its intended frequency of operation. This is a simple antenna that radiates its energy out toward the horizon (perpendicular to the antenna). The patterns shown are those resulting from a perfect dipole formed with two thin wires oriented vertically along the z-axis.

Reference:
https://www.cisco.com/c/en/us/products/collateral/wireless/aironet-antennas-accessories/prod_white_paper0900a

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

The network administrator must be able to perform configuration changes when all the RADIUS servers are unreachable. Which configuration allows all commands to be authorized if the user has successfully authenticated?

• A.aaa authorization exec default group radius if-authenticated
• B.aaa authentication login default group radius local none
• C.aaa authorization exec default group radius none
• D.aaa authorization exec default group radius

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

A network architect has partially configured static NAT. which commands should be asked to complete the configuration?

• A.R1(config)#interface GigabitEthernet0/0 R1(config)#ip nat inside
  R1(config)#interface GigabitEthernet0/1 R1(config)#ip nat outside
• B.R1(config)#interface GigabitEthernet0/0 R1(config)#ip pat inside
  R1(config)#interface GigabitEthernet0/1 R1(config)#ip pat outside
• C.R1(config)#interface GigabitEthernet0/0 R1(config)#ip pat outside
  R1(config)#interface GigabitEthernet0/1 R1(config)#ip pat inside
• D.R1(config)#interface GigabitEthernet0/0 R1(config)#ip nat outside
  R1(config)#interface GigabitEthernet0/1 R1(config)#ip nat inside

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit. Which command allows hosts that are connected to FastEthernet0/2 to access the Internet?

• A.ip nat outside source list 10 interface FastEthernet0/2 overload
• B.ip nat outside source static 209.165.200.225 10.10.10.0 overload
• C.ip nat inside source list 10 interface FastEthernet0/1 overload
• D.ip nat inside source list 10 interface FastEthernet0/2 overload
