-- Exhibit -

-- Exhibit --
Refer to the exhibit.
Which profile could be removed or changed on this virtual server to reduce CPU load on the LTM device without increasing server side bandwidth usage?

• A.httpcompression
• B.http
• C.optimized-caching
• D.tcp

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit - -- Exhibit -


Refer to the exhibits.
Which URL on which server is causing the highest latency for users?

• A./slow1.php on 172.16.20.3
• B./reflector.php on 172.16.20.2
• C./Compress.HTML on 172.16.20.1
• D./slow2.php on 172.16.20.1

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit-

-- Exhibit --
Refer to the exhibit.
An LTM Specialist has uploaded a qkview to F5 iHealth.
Within the GUI, what is the correct procedure to comply with the recommendation shown in the exhibit?

• A.Obtain product version image from downloads.f5.com.
  Import product version image.
  Install image onto BIG-IP platform.
  Select product version image and click Install.
  Select the available disk and volume set name.
• B.Log a call requesting the product version image via websupport.f5.com
  Import product version image.
  Install image onto BIG-IP platform.
  Select product version image and click Install.
  Select the available disk and volume set name.
• C.Obtain product version image from release.f5.com.
  Overwrite existing image with new product version image.
  Select product version image and click Install.
  Select the available disk and volume set name.
• D.Obtain product version image from images.f5.com.
  Overwrite existing image with new product version image.
  Select product version image and click Install.
  Select the available disk and volume set name.

Comment: *

Name: *

Email: *

Verification: *

An LTM device has been configured to log the reasons for generating TCP RST packets.
The following log entry occurs:
"01230140:3: RST sent from 192.168.1.100:80 to 192.168.1.124:39272, [0x112d82a:1721] {peer} TCP RST from remote system."
Which condition will trigger this log entry?

• A.A virtual server connection limit has been reached.
• B.The LTM device reset the connection because no pool members are available.
• C.The LTM device has reached the maximum number of allowed attempts to send the data segment to the affected TCP connection.
• D.The host at the other end terminated the TCP connection.

Comment: *

Name: *

Email: *

Verification: *

Given this as the first packet displayed of an ssldump:
2 2 1296947622.6313 (0.0001) S>CV3.1(74) Handshake
ServerHello
Version 3.1
random[32]
19 21 d7 55 c1 14 65 63 54 23 62 b7 c4 30 a2 f0
b8 c4 20 06 86 ed 9c 1f 9e 46 0f 42 79 45 8a 29
session_id[32]
c4 44 ea 86 e2 ba f5 40 4b 44 b4 c2 3a d8 b4 ad
4c dc 13 0d 6c 48 f2 70 19 c3 05 f4 06 e5 ab a9
cipherSuite TLS_RSA_WITH_RC4_128_SHA
compressionMethod NULL
In reviewing the rest of the ssldump, the application data is NOT being decrypted.
Why is ssldump failing to decrypt the application data?

• A.The BigDB Key Log.Tcpdump.Level needs to be adjusted.
• B.The data is contained within a resumed TLS session.
• C.The application data is encrypted with SSLv3.
• D.The application data is encrypted with TLSv1.
