A web application requires the client to provide the destination server and service identification.
Which HTTP header will supply this information?

• A.Host
• B.Expect
• C.From
• D.Connection

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit --
Refer to the exhibit.
An administrator created a monitor to a pool member web server, which resulted in a pool member that is marked red. The administrator knows the web server is working when it is accessed from another computer.
What should the administrator do to correct the problem?

• A.Change the default gateway on the server.
• B.Change the username and/or password on the monitor.
• C.Create a SNAT in the LTM device configuration.
• D.Change the route to the client in the LTM configuration.

Comment: *

Name: *

Email: *

Verification: *

A web developer has created a custom HTTP call to a backend application. The HTTP headers being sent by the HTTP call are:
GET / HTTP/1.1
User-Agent: MyCustomApp (v1.0)
Accept: text/html
Cache-Control: no-cache
Connection: keep-alive CookiE. somecookie=1
The backend server is responding with the following:
HTTP/1.1 400 Bad Request DatE. Wed, 20 Jul 2012 17:22:41 GMT Connection: close
Why is the HTTP web server responding with a HTTP 400 Bad Request?

• A.The client request does NOT include a Host header.
• B.The web server is configured to accept HTTP 1.0 requests only.
• C.The User-Agent header contains an invalid character.
• D.The web server is NOT expecting a keep-alive connection.

Comment: *

Name: *

Email: *

Verification: *

These log entries can have different root causes:
Jun 28 05:01:21 LTM_A notice mcpd[27545]: 0107143a:5: CMI reconnect timer: enabled Jun 28 05:01:21 LTM_A notice mcpd[27545]: 01071431:5: Attempting to connect to CMI peer 1.1.1.2 port
6699
Jun 28 05:01:21 LTM_A notice mcpd[27545]: 01071432:5: CMI peer connection established to 1.1.1.2 port
6699
Jun 28 05:01:26 LTM_A notice mcpd[27545]: 0107143a:5: CMI reconnect timer: disabled, all peers are connected Which two commands should be used to obtain additional information on these entries? (Choose two.)

• A.bigstart status mcpd
• B.tmsh show /sys mcpd
• C.tmsh modify /sys db log.cmi.level value debug
• D.tmsh modify /sys db log.mcpd.level value debug

Comment: *

Name: *

Email: *

Verification: *

An LTM Specialist troubleshooting an issue looks at the following /var/log/ltm entries:
Oct 2 04:52:42 slot1/tmm7 crit tmm7[21734]: 01010201:2: Inet port exhaustion on 10.143.109.5 to
10.143.147.150:53 (proto 17)
Oct 2 05:37:16 slot1/tmm7 crit tmm7[21734]: 01010201:2: Inet port exhaustion on 10.143.109.5 to
10.143.147.150:53 (proto 17)
Oct 2 05:57:32 slot1/tmm2 crit tmm2[21729]: 01010201:2: Inet port exhaustion on 10.143.109.5 to
10.143.147.150:53 (proto 17)
Oct 2 06:30:03 slot1/tmm7 crit tmm7[21734]: 01010201:2: Inet port exhaustion on 10.143.109.5 to
10.143.147.150:53 (proto 17)
Oct 2 06:37:44 slot1/tmm2 crit tmm2[21729]: 01010201:2: Inet port exhaustion on 10.143.109.5 to
10.143.147.150:53 (proto 17)
Oct 2 06:47:05 slot1/tmm5 crit tmm5[21732]: 01010201:2: Inet port exhaustion on 10.143.109.5 to
10.143.147.150:53 (proto 17)
Which configuration item should the LTM Specialist review to fix the issue?

• A.Virtual Server Port Translation
• B.Pool Member
• C.SNAT Pool
• D.Port Lockdown
