An LTM device is monitoring three pool members. One pool member is being marked down.
What should the LTM Specialist enable to prevent the server from being flooded with connections once its monitor determines it is up?

• A.hold down timer
• B.packet shaping
• C.manual resume
• D.fastest load balance algorithm
• E.slow ramp timer

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit-

-- Exhibit -
Refer to the exhibit.
An LTM Specialist configures a virtual server that balances HTTP connections to a pool of three application servers. Approximately one out of every three connections to the virtual server fails.
Which two actions will resolve the problem? (Choose two.)

• A.Enable SNAT automap on the virtual server.
• B.Verify the default gateway on the application servers.
• C.Verify that port lockdown is set to allow port 80.
• D.Assign a custom HTTP monitor to the pool.
• E.Increase the TCP timeout value in the default TCP profile.

Comment: *

Name: *

Email: *

Verification: *

An LTM Specialist has set up a custom SNMP alert.
Which command line tool should the LTM Specialist use to test the alert?

• A.snmptest
• B.testlog
• C.logtest
• D.logger

Comment: *

Name: *

Email: *

Verification: *

A virtual server for a set of web services is constructed on an LTM device. The LTM Specialist has created an iRule and applied this iRule to the virtual server:
when HTTP_REQUEST {
switch [HTTP::uri] {
"/ws1/ws.jsp" {
log local0. "[HTTP::uri]-Redirected to JSP Pool"
pool JSP
}
default { log local0. "[HTTP::uri]-Redirected to Non-JSP Pool"
pool NonJSP
} } } However, the iRule is NOT behaving as expected. Below is a snapshot of the log: /WS1/ws.jsp-Redirected to JSP Pool /WS1/ws.jsp-Redirected to JSP Pool /WS1/ws.jsp-Redirected to JSP Pool /WS1/WS.jsp-Redirected to Non-JSP Pool /ws1/WS.jsp-Redirected to Non-JSP Pool /WS1/ws.jsp-Redirected to JSP Pool /ws1/ws.jsp-Redirected to Non-JSP Pool
What should the LTM Specialist do to resolve this?

• A.Select the "Process Case-Insensitivity" option for the virtual server.
• B.Set the "Case Sensitivity" option of each member to "None".
• C.Use the followinG.switch -lc [HTTP::uri]
• D.Use the followinG.switch [string tolower [HTTP::uri]]

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -


-- Exhibit --
Refer to the exhibits.
An LTM Specialist is reconfiguring a virtual server to redirect all clients to HTTPS. Testing reveals that the redirect is functioning incorrectly. As part of the troubleshooting process, the LTM Specialist performs a packet capture.
What is the issue?

• A.The redirect is sending the client to the incorrect location.
• B.The virtual server is missing a clientssl profile.
• C.The virtual server is incorrectly processing the HTTP request.
• D.The redirect is causing an infinite loop.
