-- Exhibit -

-- Exhibit -Refer to the exhibit.
An LTM Specialist is troubleshooting an issue with a new virtual server. When connecting through the virtual server, clients receive the message "The connection was reset" in the browser. Connections directly to the pool member show the application is functioning correctly.
What is the issue?

• A.The pool member is failing the monitor check.
• B.The pool member default gateway is set incorrectly.
• C.The virtual server is configured with the incorrect SNAT address.
• D.The virtual server is processing encrypted traffic as plain-text HTTP.

Comment: *

Name: *

Email: *

Verification: *

An LTM Specialist has been asked to configure a virtual server to distribute connections between a pool of two application servers with addresses 172.16.20.1 and 172.16.20.2. The application servers are listening on TCP ports 80 and 443. The application administrators have asked that clients be directed to the same node for both HTTP and HTTPS requests within the same session.
Virtual servers vs_http and vs_https have been created, listening on 1.2.3.100:80 and 1.2.3.100:443, respectively.
Which configuration option will result in the desired behavior?

• A.Create pool http_pool with members 172.16.20.1:80 and 172.16.20.2:80 Create pool https_pool with members 172.16.20.1:443 and 172.16.20.2:443 Assign http_pool as the default pool for vs_http Assign https_pool as the default pool for vs_https Create an SSL persistence profile with "match across virtual servers" enabled Assign the persistence profile to vs_http
• B.Create pool http_pool with members 172.16.20.1:80 and 172.16.20.2:80 Assign pool http_pool as the default pool for both vs_https and vs_https Disable port translation for vs_https Create an SSL persistence profile with "match across virtual servers" enabled Assign the persistence profile to vs_http.
• C.Create pool http_pool with members 172.16.20.1:80 and 172.16.20.2:80 Create pool https_pool with members 172.16.20.1:443 and 172.16.20.2:443 Assign http_pool as the default pool for vs_http Assign https_pool as the default pool for vs_https Create a source address persistence profile with "match across services" enabled Assign the persistence profile to vs_http and vs_https
• D.Create pool app_pool with members 172.16.20.1:any and 172.16.20.2:any Assign app_pool as the default pool for both vs_http and vs_https Disable port translation for vs_http and vs_https

Comment: *

Name: *

Email: *

Verification: *

An F5 LTM Specialist needs to perform an LTM device configuration backup prior to RMA swap.
Which command should be executed on the command line interface to create a backup?

• A.bigpipe config save /var/tmp/backup.ucs
• B.tmsh save /sys ucs /var/tmp/backup.ucs
• C.tmsh save /sys config ucs /var/tmp/backup.ucs
• D.tmsh save /sys config /var/tmp/backup.ucs

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit -
Refer to the exhibit.
An LTM Specialist is troubleshooting an issue with an application configured on an LTM device. The application works properly when accessed directly via the servers; however, it does not work when accessed via the LTM device. The virtual server, 192.168.1.211:443, is configured to SNAT using the address 192.168.1.144 and references a pool with the member 192.168.10.80:443. The virtual server has no Client or Server SSL profiles associated.
Which configuration change will allow the application to function through the virtual server?

• A.Add SSL off-loading to the pool member.
• B.Add Client and Server SSL profiles to the virtual server.
• C.Change pool member port to 8443.
• D.Change virtual server port to 8443.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit-

-- Exhibit -Refer to the exhibits.
Every monitor has the same Send String, Recv String, and an Alias of *:*. The LTM Specialist simplifies the configuration to minimize the number of monitors.
How many unique monitors remain?

• A.5
• B.4
• C.2
• D.1
• E.3
