An LTM Specialist is working with an LTM device configured with 10 virtual servers on the same domain with a different key/cert pair per virtual. For examplE. www.example.com; ftp.example.com; ssh.example.com; ftps.example.com.
What should the LTM Specialist do to reduce the number of objects on the LTM device?

• A.create a wildcard certificate and use it on all *.example.com virtual servers
• B.create a 0 port virtual server and have it answer for all protocols
• C.create a 0.0.0.0:0 virtual server thus eliminating all virtual servers
• D.create a transparent virtual server thus eliminating all virtual servers

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit-


-- Exhibit -
Refer to the exhibits.
How should the LTM Specialist minimize the configuration?

• A.Remove the pool member level monitors.
• B.The configuration is as minimized as possible.
• C.Create a single monitor, apply it to the pool, and remove the pool member level monitors.
• D.Create a single monitor and apply it to each pool member.

Comment: *

Name: *

Email: *

Verification: *

A new VLAN vlan301 has been configured on a highly available LTM device in partition ApplicationA. A new directly connected backend server has been placed on vlan301. However, there are connectivity issues pinging the default gateway. The VLAN self IPs configured on the LTM devices are 192.168.0.251 and 192.168.0.252 with floating IP
192.168.0.253. The LTM Specialist needs to perform a packet capture to assist with troubleshooting the connectivity.
Which command should the LTM Specialist execute on the LTM device command line interface to capture the attempted pings to the LTM device default gateway on VLAN vlan301?

• A.tcpdump -ni vlan301 'host 192.168.0.251 or host 192.168.0.252'
• B.tcpdump -ni vlan301 'host 192.168.0.253'
• C.tcpdump -ni /ApplicationA/vlan301 'host 192.168.0.253'
• D.tcpdump -ni /ApplicationA/vlan301 'host 192.168.0.251 or host 192.168.0.252'

Comment: *

Name: *

Email: *

Verification: *

The pool members are serving up simple static web content.
The current virtual server configuration is given as follows: tmsh list ltm virtual simple
ltm virtual simple { destination 10.10.10.10:80 ip-protocol tcp mask 255.255.255.255 profiles { http { } httpcompression { } oneconnect { } tcp { } } snat automap vlans-disabled
}
tmsh list ltm pool simple_pool ltm pool simple_pool { members {
10.10.10.11:80 { address 10.10.10.11 }
10.10.10.12:80
{ address 10.10.10.12 }
10.10.10.12:80
{ address 10.10.10.13 } }
}
Which three objects in the virtual server configuration can be removed without disrupting functionality of the virtual server? (Choose three.)

• A.http
• B.snat automap
• C.httpcompression
• D.oneconnect
• E.tcp

Comment: *

Name: *

Email: *

Verification: *

An LTM Specialist is customizing local traffic logging.
Which traffic management OS alert level provides the most detail?

• A.Notice
• B.Critical
• C.Informational
• D.Emergency
• E.Alert

Comment: *

Name: *

Email: *

Verification: *
