The LTM Specialist is in the process of creating a USB boot drive for the purpose of restoring the BIG-IP software to an LTM device. A separate LTM device has been selected for the purpose of creating the USB boot drive. The BIG-IP software ISO has already been uploaded and mounted on the separate LTM device.
Which command should the LTM Specialist use to trigger the LTM device to install the BIG-IP software to the USB boot drive?

• A.mkdisk
• B.bigip_software_create
• C.install
• D.tmsh

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit --
Refer to the exhibit.
A user is unable to access a secure application via a virtual server.
What is the cause of the issue?

• A.The virtual server does NOT have a client SSL profile configured.
• B.The client and server CANNOT agree on a common cipher.
• C.The client authentication failed.
• D.The virtual server does NOT have a pool configured.

Comment: *

Name: *

Email: *

Verification: *

An LTM device has a virtual server configured as a Performance Layer 4 virtual listening on 0.0.0.0:0 to perform routing of packets to an upstream router. The client machine at IP address 192.168.0.4 is attempting to contact a host upstream of the LTM device on IP address 10.0.0.99.
The network flow is asymmetrical, and the following TCP capture displays:
# tcpdump -nnni 0.0 'host 192.168.0.4 and host 10.0.0.99'
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode listening on 0.0, link-type EN10MB (Ethernet), capture size 96 bytes
05:07:55.499954 IP 192.168.0.4.35345 > 10.0.0.99.443: S 3205656213:3205656213(0) ack 3267995082 win
1480
05:07:55.499983 IP 10.0.0.99.443 > 192.168.0.4.35345: R 1:1(0) ack 1 win 0
05:07:56.499960 IP 192.168.0.4.35345 > 10.0.0.99.443: S 3205656213:3205656213(0) ack 3267995082 win
1480
05:07:56.499990 IP 10.0.0.99.443 > 192.168.0.4.35345: R 1:1(0) ack 1 win 0
4 packets captured
Which option within the fastL4 profile needs to be enabled by the LTM Specialist to prevent the LTM device from rejecting the flow?

• A.Generate Initial Sequence Number
• B.Loose Initiation
• C.Reset on Timeout
• D.Loose Close

Comment: *

Name: *

Email: *

Verification: *

An IT administrator wants to log which server is being load balanced to by a user with IP address 10.10.10.25.
Which iRule should the LTM Specialist use to fulfill the request?

• A.when SERVER_CONNECTED {
  if { [IP::addr [IP::remote_addr]] equals 10.10.10.25]} {
  log local0. "client 10.10.10.25 connected to pool member [IP::addr [LB::server addr]]" }
  }
• B.when CLIENT_ACCEPTED {
  if { [IP::addr [IP::remote_addr] equals 10.10.10.25]} {
  log local0. "client 10.10.10.25 connected to pool member [IP::addr [LB::server addr]]" }
  }
• C.when CLIENT_ACCEPTED {
  if { [IP::addr [clientside [IP::remote_addr]] equals 10.10.10.25]} {
  log local0. "client 10.10.10.25 connected to pool member [IP::addr [LB::server addr]]" }
  }
• D.when SERVER_CONNECTED {
  if { [IP::addr [clientside [IP::remote_addr]] equals 10.10.10.25]} {
  log local0. "client 10.10.10.25 connected to pool member [IP::addr [LB::server addr]]" }
  }

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -


-- Exhibit --
Refer to the exhibits.
Users are able to access the application when connecting directly to the web server but are unsuccessful when connecting to the virtual server. Return traffic bypasses the LTM device using Layer 2 nPath routing.
Which configuration change resolves this problem?

• A.Disable address translation on the LTM device.
• B.Configure the VIP address on the loopback interface of the web server.
• C.Configure a route on the web server to the client subnet.
• D.Enable a SNAT pool on the LTM device.
• E.Configure the virtual server to listen on port 80 on the LTM device.
