A virtual server is defined using a sourceEladdress based persistence profile. The
last five connections were A, B, C, A, C . Given the conditions shown in the graphic,
if a client with IP address 205.12.45.52 opens a connection to the virtual server,
which member will be used for the connection.

• A.10.10.20.1:80
• B.10.10.20.4:80
• C.10.10.20.2:80
• D.10.10.20.3:80
• E.10.10.20.5:80

Comment: *

Name: *

Email: *

Verification: *

A BIG-IP Administrator plans to resolve a non-critical issue with a BIG-IP device in 2 weeks. What Severity level should be assigned to this type of F5 support ticket?

• A.3
• B.4
• C.1
• D.2

Comment: *

Name: *

Email: *

Verification: *

A BIG-IP Administrator needs to apply a health monitor for a pool of database servers named DB_Pool that uses TCP port 1521.
Where should the BIG-IP Administrator apply this monitor?

• A.Local Traffic > Pools > DB Pool > Properties
• B.Local Traffic > Pools > De Pool > Members
• C.Local Traffic > Profiles > Protocol > TCP
• D.Local Traffic > Nodes > Default Monitor

Comment: *

Name: *

Email: *

Verification: *

A BIG-IP Administrator needs to restore a UCS file to an F5 device using the Configuration Utility. Which section of the Configuration Utility should the BIG-IP Administrator access to perform this task?

• A.System > Configuration
• B.Local Traffic > Virtual Servers
• C.Local Traffic > Policies
• D.System > Archives

Comment: *

Name: *

Email: *

Verification: *

An IT support engineer needs to access and modify Virtual Servers in three partitions (Common /Banking and Dev) daily on a BIG-IP device. The company operates a Least Privilege access policy. What level of access does the IT support engineer need to ensure completion of daily roles?

• A.Application Editor in /Common, /Banking, and /Dev partitions
• B.Application Editor in all partitions
• C.Manager in all partitions
• D.Manager in /common/Banking, and /Dev partitions
