-- Exhibit -

-- Exhibit --
Refer to the exhibit.
A layer 2 nPath routing configuration has been deployed. A packet capture contains a client connection packet with the following properties:
Source IP: <Virtual Server>
Destination IP: <Client A>
At which two locations could the packet capture have been taken? (Choose two.)

• A.the external VLAN interface of the LTM device
• B.the internal interface of the Internet firewall
• C.the DMZ interface of the Internet firewall
• D.the network interface of web server

Comment: *

Name: *

Email: *

Verification: *

An LTM Specialist is troubleshooting a problem on an eCommerce website. The user browses the online store using port 80, adding items to the shopping cart. The user then clicks the "Checkout" button on the site, which redirects the user to port 443 for the checkout process. Suddenly, the user's shopping cart is shown as empty. The shopping cart data is stored in memory on the server, and the default source address persistence profile is used on both virtual servers.
How should the LTM Specialist resolve this issue?

• A.Enable SNAT Automap on both virtual servers.
• B.Create a custom persistence profile and enable "Map Proxies."
• C.Add an HTTP profile to both virtual servers.
• D.Create a custom persistence profile and enable "Match Across Services."

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -


-- Exhibit -
Refer to the exhibits.
After upgrading LTM from v10 to v11, users are unable to connect to an application. The virtual server is using a client SSL profile for re-terminating SSL for payload inspection, but a server SSL profile is being used to re-encrypt the request.
A client side ssldump did NOT show any differences between the traffic going directly to the server and the traffic being processed by the LTM device. However, packet capture was done on the server, and differences were noted.
Which modification will allow the LTM device to process the traffic correctly?

• A.Change to different ciphers on the server SSL profile.
• B.Change Secure Renegotiation to "Request."
• C.Enable ProxySSL option in the server SSL profile.
• D.Enable Strict Resume.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit --
Refer to the exhibit.
A pair of LTM devices are configured for HA. The LTM Specialist observes from a capture that there is a successful connection from a client directly to a web server and an unsuccessful connection from a client via the LTM device to the same web server.
Which two solutions will solve the configuration problem? (Choose two.)

• A.Configure SNAT on the virtual server.
• B.Change server default gateway to point at LTM internal floating IP.
• C.Change server default gateway to point at LTM internal self IP.
• D.Configure SNAT on the pool.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit --

-- Exhibit --
Refer to the exhibit.
A company uses a complex piece of client software that connects to one or more virtual servers (VS) hosted on an LTM device. The client software is experiencing issues. An LTM Specialist must determine the cause of the problem.
The LTM Specialist is seeing a client source IP of 168.210.232.5 in the tcpdump. However, the client source IP is actually 10.123.17.12.
Why does the IP address of 10.123.17.12 fail to appear in the tcpdump?

• A.The LTM device performed NAT on the individual's IP address.
• B.The Secure Network Address Translation (SNAT) pool on the virtual server is activated.
• C.Network Address Translation (NAT) has occurred in the path between the client and the LTM device.
• D.The individual's data stream is being routed to the LTM device by a means other than the default route.
