-- Exhibit-

-- Exhibit --
Refer to the exhibit.
A pair of LTM devices is configured for HA.
What happens if the pool member server with IP address 10.0.0.4 becomes totally
unresponsive to the active LTM device, but is still responsive to the standby LTM device?

• A.The HA-group will initiate a fail-over because the threshold is set to 2.
• B.The HA-group will initiate a fail-over because the HA-Group score will be zero.
• C.The HA-group will disable the trunk my_trunk.
• D.The HTTP application will be unavailable via the LTM device.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit --
Refer to the exhibit.
An LTM Specialist has created a virtual server to balance connections to a pool of application servers and offload SSL decryption. Clients connect to the application at https://www.example.com/. The virtual server is configured with a clientssl profile but no serverssl profile. The application servers are listening on ports
80 and 443. Users are unable to connect to the application through the virtual server but are able to connect directly to the application server.
What is the root cause of the error?

• A.The LTM device is chunking responses.
• B.The pool members are configured with the wrong port.
• C.The LTM device is redirecting users to HTTPS.
• D.The application servers are redirecting users to HTTPS.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit --
Refer to the exhibit.
An LTM Specialist configures a virtual server that balances HTTP connections to a pool of three application servers. Approximately one out of every three connections to the virtual server fails.
Which two actions will resolve the problem? (Choose two.)

• A.Verify the default gateway on the application servers.
• B.Enable SNAT automap on the virtual server.
• C.Assign a custom HTTP monitor to the pool.
• D.Verify that port lockdown is set to allow port 80.
• E.Increase the TCP timeout value in the default TCP profile.

Comment: *

Name: *

Email: *

Verification: *

The following decoded TCPDump capture shows the trace of a failing health monitor.
00:00:13.245104 IP 10.29.29.60.51947 > 10.0.0.12.http: P 1:59(58) ack 1 win 46 <nop,nop,timestamp
2494782300 238063789> out slot1/tmm3 lis
0x0000: 4500 006e 3b19 4000 4006 ce0c 0a1d 1d3c E..n;.@.@......<
0x0010: 0a00 000c caeb 0050 8be5 aca3 dd65 e3e1 .......P.....e..
0x0020: 8018 002e 1b41 0000 0101 080a 94b3 5b5c .....A........[\
0x0030: 0e30 90ad 4745 5420 2f74 6573 745f 7061 .0..GET./test_pa
0x0040: 6765 2e68 746d 6c20 4854 5450 312e 310d ge.html.HTTP1.1.
0x0050: 0a48 6f73 743a 200d 0a43 6f6e 6e65 6374 .Host:...Connect
0x0060: 696f 6e3a 2043 6c6f 7365 0d0a 0d0a 0105 ion:.Close......
0x0070: 0100 0003 00 .....
00:00:13.245284 IP 10.0.0.12.http > 10.29.29.60.51947: . ack 59 win 362 <nop,nop,timestamp 238063789
2494782300> in slot1/tmm3 lis
0x0000 0ffd 0800 4500 00c9 6f68 4000 8006 755d [email protected]]
0x0010 0a29 0015 0a29 0103 0050 e0d6 4929 90eb .)...)...P..I)..
0x0020 6f12 d83c 8019 fab3 9b31 0000 0101 080a o..<.....1......
0x0030 0068 4e10 5240 6150 4854 5450 2f31 2e31 .hN.R@aPHTTP/1.1
0x0040 2034 3030 2042 6164 2052 6571 7565 7374 .400.Bad.Request
0x0050 0d0a 436f 6e74 656e 742d 5479 7065 3a20 ..Content-Type:.
0x0060 7465 7874 2f68 746d 6c0d 0a44 6174 653a text/html..Date:
0x0070 2054 6875 2c20 3231 204a 616e 2032 3031 .Mon,.01.Jan.201
0x0080 3020 3138 3a35 383a 3537 2047 4d54 0d0a 2.00:00:01.GMT..
0x0090 436f 6e6e 6563 7469 6f6e 3a20 636c 6f73 Connection:.clos
0x00a0 650d 0a43 6f6e 7465 6e74 2d4c 656e 6774 e..Content-Lengt
0x00b0 683a 2032 300d 0a0d 0a3c 6831 3e42 6164 h:.20....<h1>Bad
0x00c0 2052 6571 7565 7374 3c2f 6831 3e .Request</h1>
The health monitor is sending the string shown in the capture; however, the server response is NOT as expected. The correct response should be an HTML page including the string 'SERVER IS UP'.
What is the issue?

• A.Incorrect syntax in send string. 'HTTP1.1' should be 'HTTP/1.1'.
• B.The /test_page.html does NOT exist on the web server.
• C.The wrong HTTP version is specified in the send string. Version 1.2 should be used instead of version 1.1.
• D.Incorrect syntax in send string. 'Connection: Close' should be 'Connection: Open'.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit -
Refer to the exhibit.
A company uses a complex piece of client software that connects to one or more virtual servers (VS) hosted on an LTM device. The client software is experiencing issues. An LTM Specialist is tasked with finding the cause of the problem.
The LTM Specialist has the tcpdump extract and knows the client software has at least one connection to a VS on port 1990. However, when a tcpdump runs on the internal VLAN, there is no record of port 1990 in the tcpdump.
Why is there no record of port 1990 in the tcpdump?

• A.The LTM device drops the connection.
• B.Explanation:
  -- Exhibit -

  -- Exhibit -Refer to the exhibit. A company uses a complex piece of client software that connects to one or more virtual servers
  hosted on an LTM device. The client software is experiencing issues. An LTM Specialist must determine the cause of the problem.
  The LTM Specialist has the tcpdump extract and knows the client source IP is 168.210.232.5. Assuming no wildcard virtual servers, how many distinct virtual servers does the client connect to on the LTM device?
  A.2
  B.3
  C.4
  D.6
• C.The LTM device performs a Network Address Translation (NAT).
• D.The LTM device performs a Port Address Translation (PAT).
• E.Port 1990 is a well-known port, so its use is restricted.
