-- Exhibit --

-- Exhibit --
Refer to the exhibit.
A company uses a complex piece of client software that connects to one or more virtual servers (VS) hosted on an LTM device. The client software is experiencing issues. An LTM Specialist must determine the cause of the problem. The LTM Specialist has the tcpdump extract. The client loses connection with the LTM device.
Where is the reset originating?

• A.the local switch
• B.the device initiating the connection
• C.the application server
• D.the destination device of the initial connection

Comment: *

Name: *

Email: *

Verification: *

Which command line interface command will check if the BIG-IP platform contains a packet velocity ASIC (PVA)?

• A.tmsh show /sys hardware | grep -i pva
• B.tmsh show /sys hardware pva status
• C.tmsh show /ltm hardware | grep -i pva
• D.bigpipe platform show | grep -i pva

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit-

-- Exhibit -Refer to the exhibit.
An HTTP monitor always marks the nodes in the pool as down. The monitor's definition and the HTTP headers from the monitor request and response are provided.
What is the issue?

• A.The monitor is NOT configured to follow the redirect.
• B.The send string is incorrect.
• C.The response is compressed.
• D.The monitor timeout is too short.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit-
-- Exhibit -
Refer to the exhibit.
An LTM Specialist has created a virtual server to load balance traffic to a pool of HTTPS servers. The servers use client certificates for user authentication. The virtual server has clientssl, serverssl, and http profiles enabled. Clients are unable to connect to the application through the virtual server. Clients are able to connect to the application servers directly.
What is the root cause of the problem?

• A.The clientssl profile is NOT set to require a client certificate.
• B.The application server does NOT see the client certificate due to SSL offload.
• C.The LTM device does NOT trust the issuing CA of the client certificate.
• D.The application server does NOT support 2048-bit keys.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit -

-- Exhibit --
Refer to the exhibit.
An LTM Specialist is investigating reports that users are unable to perform some commands through an FTP virtual server. The LTM Specialist performs a capture on the server side of the LTM device.
What is the issue with the application?

• A.data connection failing
• B.command connection failing
• C.PORT command disallowed
• D.LIST command disallowed
