Exhibit:

Referring to the exhibit, you need to implement VPLS between CE-A1 and CE-A2 You must ensure that no loops are created due to the multihoming of the connection from CE-A2 to PE2 and PE3.
Based on the type of VPLS, which two solutions will satisfy this requirement? (Choose two.)

• A.In an LDP VPLS. configure multihoming and local preference on PE-2 and PE-3
• B.In a BGP VPLS, configure a primary and backup neighbor.
• C.In a BGP VPLS, configure multihoming and local preference on PE-2 and PE-3.
• D.In an LDP VPLS, configure a primary and backup neighbor.

Comment: *

Name: *

Email: *

Verification: *

Exhibit:

Your network connects two segments of your customer's network as shown in the exhibit They need to exchange routes between Segment 1 and Segment 2 but both segments use the same AS number.
Which two steps will accomplish this task? (Choose two.)

• A.Configure the BGP group with the advertise-peer-as parameter on routers R2 and R3.
• B.Configure the BGP group with the as-override parameter on routers R1 and R4.
• C.Configure the routing-options autonomous-system loops l parameter on routers R2 and R3.
• D.Configure the routing-options autonomous-system loops l parameter on routers R1 and R4.

Comment: *

Name: *

Email: *

Verification: *

Exhibit:

Referring to the exhibit, hosts in Site 1 and Site 2 are unable to communicate with each other through the Layer 3 VPN.
What is the problem?

• A.The two sites are using the same route distinguishes.
• B.The two sites are using the same route target.
• C.The two sites are using the same instance type.
• D.The two sites are in the same AS.

Comment: *

Name: *

Email: *

Verification: *

Referring to the exhibit, which path would traffic passing through R1 take to get to R6?

• A.R1 -> R2 -> R4 -> R6
• B.R1 -> R2 -> R3 -> R6
• C.R1 -> R3 -> R5 -> R6
• D.R1 -> R3 -> R4 -> R6

Comment: *

Name: *

Email: *

Verification: *

Which two statements are true about what a route reflector does by default when distributing routes it has received from reflector clients? (Choose two.)

• A.It does not change any received BGP attributes.
• B.It sets the next hop of all routes to "self' to prevent routing loops.
• C.It changes the default BGP attributes to inform peers that it is a route reflector.
• D.It adds its cluster ID to the client-received routes.
