Exhibit:

CE-1, CE-2, and CE-3 are part of a single VPLS VPN An Ethernet frame has just arrived at PE-3 from CE-3.
It has a source MAC address of CE-3 and a destination MAC address of CE-1. You want to know what PE-3 does with the Ethernet frame.
Referring to the exhibit, which statement is correct?

• A.It drops the packet because the destination MAC address is not for PE-3.
• B.It forwards the packet to PE-1 and PE-2.
• C.It drops the packet because the destination MAC address is not in PE-3's MAC table.
• D.It forwards the packet to PE-1 only.

Comment: *

Name: *

Email: *

Verification: *

Exhibit.

Referring to the exhibit, which OSPFv3 configuration is implemented on router R1?
A)

B)

C)

D)

• A.Option A
• B.Option C
• C.Option D
• D.Option B

Comment: *

Name: *

Email: *

Verification: *

You are troubleshooting a problem with a BGP peer where BGP routes are not being accepted from that peer.
Referring to the exhibit, which two statements are correct? (Choose two.)

• A.The reject at the end of the policy is preventing the routes from being accepted.
• B.Term 0 is missing a route-filter that specifies the allowed routes.
• C.Term 0 is missing a terminating action that allows BGP routes to be accepted.
• D.You cannot have terminating actions outside of terms.

Comment: *

Name: *

Email: *

Verification: *

Exhibit:

All networks shown in the exhibit contain more than one BGP speaker You operate ISP A and must ensure that Customer Y sends their traffic to you over the directly connected link. Customer Y is not to be used for transit into your network.
What would you do to accomplish this task?

• A.Advertise routes to Customer X with the custom defined 0:0 community
• B.Advertise routes to Customer Y with the well-known no-export community
• C.Advertise routes to Customer Y with the custom defined 65535:65535 community.
• D.Advertise routes to Customer X with the well-known no-advertise community.

Comment: *

Name: *

Email: *

Verification: *

Exhibit:

R2 is receiving a route from R1 and you must ensure that the route is not advertised to R3.
Referring to the exhibit, which two configurations on R2 will solve the issue? (Choose two.)

• A.Apply the no-export policy as an export policy under group 65003
• B.Apply the no-export policy as an import policy under group 65001
• C.Apply the no-advertise policy as an export policy under group 65003
• D.Apply the no-advertise policy as an import policy under group G5001
